Model TCW Series -Wheel Offset Disk Harrow

FromRome Plow Company, LLC

SHARE

For use with tractors in the 30 – 114hp range.

Most popular related searches

offset disc harrow

wheel offset disc harrow

tillage machine

tractor equipment

Heavy duty proven design with rugged boxed angle construction welded for maximum strength and rigidity.
High gang carrier design to prevent trash build up and clogging.
Levels, cuts, and mixes to full working depth.
Combines ease of maneuverability with high strength for the most adverse conditions.
Up to 178lbs (81kg) of weight per disk blade depending on model with an average of 171lbs (78kg).
Up to 8” (203mm) maximum depth of penetration with standard 24” (610mm) diameter disk blades.
Equipped with Timken dual tapered roller bearings.
Adjustable disk blade scrapers.
Dual purpose transport unit for transportability and penetration control.

24” (610mm) diameter x 1/4” (6mm) thick, cutout (notched) deep concavity disk blades.
Adjustable disk blade scrapers.
Heat treated alloy steel gang axles.
Heavy duty cast steel spacer spools.
Heavy duty bearing wear plates.
New industrial tires – 2 each. TCW-16 thru TCW-24: 12.5L x 15 – 12 ply. TCW-28 and TCW-32: 7.5 x 16 – 12 ply. TCW-36 and TCW-40: 12.5L x 15 – 12 ply.
Hydraulic control group includes cylinders, hose holders, and hoses with fittings to reach rear of tractor.
Two heavy duty gang wrenches.
Drawbar jack stand and safety chain.

26” (660mm) diameter x 1/4” (6mm) thick, cutout (notched) deep concavity disk blades.
Cylinder rod stops for positive depth control adjustment.
Drawbar clevis for track type tractors
