Model TFZ 90 - Tilt Feller
From Tilt Feller
The Tilt Folding Tongs TFZ 90 was developed by our partner company, Bachmaier agricultural engeneering.The pliers designed for the Sennebogen 718 material handler are capable of handling log diameters of up to 700 millimeters. The sword length is 900 mm. The max. Gripper opening is 1870 mm, the minimum trunk diameter should not be less than 110 mm.
-
Most popular related searches
Technical Specifications
Technical Data: Saw
- Typ: Hultdins
- Saw displacement: 19 ccm
- Saw chain: 0,404″
- Saw bar: 90 cm
- max. cut diameter: 70 cm
- chain tension: hydraulic
- chain lubrication: integrated
Gripper
- max gripper range: 187 cm
- min stem diameter: 11 cm
- tilt range: 182 degree
- torque tilt: 11 kN (210 bar)
- rotor turn range: 282 degree
- torque turn 7,4 kN (210 bar)
Connection adaptable
- min oil requirements: ca. 190 l / min
- weight: 1020 kg
