FELLA-Werke GmbH - a brand by AGCO Corporation

Model TH 4504 DN, TH 5204 DN, TH 6606 DN, TH 7706 DN - Three-Point Attachmen Hay Tedder



The classic all-rounders in the FELLA range of hay tedders, with which you can produce high-quality forage in any region and under an extremely wide range of different operating conditions, are designed for the fitting of a three-point attachment and equipped with a trailing device.

These models attract prospective buyers due to their sturdy construction and compact transportation dimensions as well as because of their flexibility in regard to cost-effectiveness and work output. As with all FELLA hay tedders, the forage is picked up by the tines and turned gently without suffering damage. A light, loose and well-mixed mat of forage is created, representing top-quality forage material. With the central edge spreading device which is fitted as standard, edges of fields no longer present any problems – it's all high-quality forage down to the last blade of grass. Because of the spreading angle adjustment system, you can also always optimally adapt your machine to the harvesting situation, whatever it is.

Through the patented traction compression system, the weight of the machine is transferred onto the lower links. The towing point between hay tedder and tractor is then positioned very low. As a result, no bending moment is produced and there is no wear on the three-point headstock. When lifting the machine at the headland, the hay tedder is automatically centralised, which provides safe and stable driving behaviour. When back at work, the system again ensures optimum ground contour following and excellent trailing behaviour of the hay tedder. Even when travelling downhill, the machine does not run into the back of the tractor. The tines are reliably prevented from piercing the ground, thereby sparing your sward from mechanical damage. Forage contamination is kept to a minimum, providing top-quality forage thanks to the FELLA patent.

The three-point hay tedders are equipped with an integrated, adjustable swing brake. The brake reliably prevents the hay tedder from generating a rocking motion where there are heavy deposits of forage or the tractor and machine are travelling at relatively high speeds.

The rotors are easily folded in and out hydraulically in a synchronised operation directly from the tractor seat. Safe operation is also possible when working on hillsides thanks to this synchronised lifting facility. When the machine is folded to the transport position, the automatic safety switch-off is activated, with the rotors merely freewheeling. This reliably protects the machines from the consequences of incorrect operation and guarantees safe travel out on the road.

At a glance:
  • Optimum ground contour following – excellent trailing behaviour
  • Short attachment to the tractor
  • No trailing machine overrun thanks to swing brake
  • Central edge spreading device as standard
  • Super C tines
