Model TR -Tunnel Sprayer
FromBertoni S.r.l
Ideal for working in rows 2.00 to 3.80 metres apart. Full drain fibreglass tank with internal isophthalic treatment. Built-in circuit washing tank. Independent hand-washing tank. Ø400 H333 mm stainless steel basket for filtering water input into tank. Dispensing and mixing pump + retrieval pump made of brass with Viton membranes. Product mixing in ENAMA-certified tank with “Venturi” system. Chemical suction unit with hydro-venturi system for inserting products into tank.
Most popular related searches
- Easily accessible filtering system with a high working autonomy
- Alternator with “Brushless” technology
- IP68 electric fans + stainless steel protection grid
- Fibreglass RTM panels with drain plugs
- Liquid interception wall can open to ease cleaning procedures
- Brass and Viton nozzle holder with ATR Albuz nozzles (Brown – Yellow)
- Motorised spray valves + pressure regulating valve with digital sensor
- Electro-hydraulic system to manage all movements (it requires 1 hydraulic distributor)
- Control panel in the cabin to control spraying and movements
- Telescopic structure made of adjustable hexagonal stainless-steel profiles
- Adjustable panel anti-collision joint
- Rear reclining footboard and handles for tank inspection
- Cataphoresis coating (sandblasting + immersion + powder coating)
- Steering drawbar with hydraulic locking system with your tractor’s couplings
- 2000 litre fibreglass tank
- 2600 litre fibreglass cistern
- S350 panels to reduce overall dimensions
- Oversized wheels for single axle 13/55-16 H=770 mm L=336 mm
- Oversize wheels for 15/55-17 single axle H=850 mm W=391 mm
- Oversize wheels for single axle 19/45-17 H=865 mm W=490 mm
- Oversize wheels for single axle 400/60-15 H=875 mm W=400 mm
- Tilting double axle with wheels 10.0/75-15.3 H=760 mm W=274 mm
- Oversize wheels for double axle 320/55-15 H=730 mm W=320 mm
- Oversize wheels for double axle 13/55-16 H=770 mm W=336 mm
- Double-axle rear wheel lifting device
- LED taillights
- LED lights to illuminate inside panels and flashing beacon
- Motor vehicle type approval under full load with hydraulic braking
- G4 cardan shaft with a homokinetic joint
- PLC computer for automatic panel management with touch display
- Hydraulic parking jack
- Stainless steel panel bumpers
- Additional nozzle
- Nozzle bar on the external panel
