Model WD-1500 and WD-2500 -Horizontal Band Saw
The only difference between the structure of the horizontal band saw and the vertical one is that the upper and lower saw wheels have become left and right saw wheels. Horizontal band saws can be equipped with movable wheels and diesel engine models, which are convenient to move to work outdoors. The diameter of the woodcut by the horizontal band saw machine is larger than that of the vertical band saw machine. It is only necessary to widen the gauge between the tracks to cut wood with a larger diameter.
Most popular related searches
Rules for the safe use of band saws
- The thickness of the band saw blade should be compatible with the matched band saw wheel. Avoid using large-thick saw blades for small wheels, which may cause breakage and injury.
- The saw tooth should be sharp, and the tooth depth should not exceed 1/4 of the width of the saw blade.
- The welding of the band saw blade should be firm and flat, the joints should be more than 3 woods, the length between the two joints should be more than 1/5 of the total length, and the thickness of the joints should be basically the same as the thickness of the saw blade.
- Strictly control the transverse cracks of the band saw blade, and the excessively long cracks should be cut off and re-welded.
- The track of the sports car of the large band saw machine should be straight, with travel switches at both ends, and warning bars should be set on both sides of the sports car. How to equip the safety device of the circular saw.
