Model WD -Vertical Band Saw
The vertical band saw has an upper saw wheel and a lower saw wheel. Generally, the lower saw wheel is the driving wheel, and the saw wheel is the driven wheel. On this pair of saw wheels, a thin steel belt with serrations on one side is a hung-band saw blade, When the saw wheel rotates, the band saw blade also rotates, so the saw teeth on the saw blade continue to move rapidly, and the wood is sawed when it comes in contact with it. Due to structural reasons, vertical band saws are generally fixed in a certain place, and the work efficiency is very high, which is suitable for some large wood processing plants.
Most popular related searches
Rules for the safe use of band saws
- The thickness of the band saw blade should be compatible with the matched band saw wheel. Avoid using large-thick saw blades for small wheels, which may cause breakage and injury.
- The saw tooth should be sharp, and the tooth depth should not exceed 1/4 of the width of the saw blade.
- The welding of the band saw blade should be firm and flat, the joints should be more than 3 woods, the length between the two joints should be more than 1/5 of the total length, and the thickness of the joints should be basically the same as the thickness of the saw blade.
- Strictly control the transverse cracks of the band saw blade, and the excessively long cracks should be cut off and re-welded.
- The track of the sports car of the large band saw machine should be straight, with travel switches at both ends, and warning bars should be set on both sides of the sports car. How to equip the safety device of the circular saw.
