BNB - Mount Sopris Digital Logging Systems
Mount Sopris has dual processor and accommodates digital multiplexed probes and is compatible with conventional pulsed output type tools. This system enables bi-directional communication with the intelligent down hole electronics. It has the following features.
Most popular related searches
- Dual processors
- Real Time data acquisition
- RS485 interface
- Up to 115Kbps data communication
- Light indicators for equipment operation
- Software programmable power supply
- Higher power output
- Diameter: 43 mm / 1.693 in
- Length: 2300 mm / 90.55 in
- Weight: 15 kg / 33.06 lb
- Shipping Weight: 18 kg / 39.68 lb
- Min. Temperature: 0oC / 32oF
- Max. Temperature: 70oC / 158oF
- Max. Pressure: 21000 kPa / 3000 PSI
- Tool Voltage Required: 40 VDC
- Tool Current Required: 170 mA
- Tool Power Required: 7 W
- Communications: Digital DOP
- Cable Conductors Required NATURAL GAMMA
- Crystal Size: 25.4 mm x 101.6mm / 1 in x 4 in NaI scintillation crystal
