Naza Infinity - Tractor Mounted Airblast Sprayers
Unlike other sprayers, the fan unit diffuser in the NAZA INFINITY line is made from 100% polyethylene. Both the rear wall and ring are made from polyethylene. This prevents the chemical attack and corrosion which normally occur with metal fan units. The position of the deflector cone behind the fan has also been designed to increase delivery air pressure.
- Polyethylene tank
- Fan unit conveyor in polyethylene
- Hot galvanised frame
- Aluminium fan with variable pitch blades and clutch
- Gerabox with two speeds and disengaging
- Manual control in aluminium with pressure regulator placed on frame
- Complete connections with R1 hydraulic type hoses
- External suction filter with non-return valve
- Inspectable hydraulic agitator
- Brass double nozzles with anti-drip device and ceramic plates
- Nozzle support booms in stainless steel
- Hand washing tank
- External graduated level gauge
- Side valve to empty tank
- Circuit washing device
- Rear bumper
- COMET ALUMINIUM: APS 71, APS 96, APS 121.
- COMET BRASS: IDS 960, IDS 1201, IDS 1401.
- ANNOVI REVERBERI ALUMINIUM: AR 813, AR 1064, AR 1203, BHA 130
- ANNOVI REVERBERI BRASS: BHS 130
Standards
All Florida sprayers are conforming with CE Standars to guarantee the operator`s safety and health protection; they also comply with the other European standards safety and environment protection.
Tank
- Actualcapacity 5% higher than nominal capacity;
- Residual liquid quantity in flat position and with inclination 10% lower than the limit allowed by the present regulation;
- Hydraulic circuit washing tank;
- Cleans water for hand-washing.
Pumps
Type diaphagram: delivery litres/min. 40/120, max pressure 40/50 bar.
Type piston: delivery litres/min. 70/90, max pressure 50/60 bar.
Nozzles
Brass double body nozzles with membrane anti dripping device of 0,5 bars. Available with ceramic plates, Albuz nozzles, Spraying Systems nozzles. Suitable for normal, medium and low volume treatments.
Fan unit
With pitch aluminium fan, two-speed gearbox, centrifugal clutch.
