HOLMER Terra Felis - Model 2 ECO -Optimum Cleaning Machine
Whatever the weather; however soiled the crop: The Terra Felis 2 eco guarantees optimum cleaning with maximum loading efficiency, and stands for maximum economic viability. With the new engine, the HOLMER-patented and height-adjustable pick-up HOLMER VarioPick, the HOLMER cleaning hybrid, automatic folding system, panorama cab and folding tank, the Terra Felis sets new standards in transfer technology.
- Individually adjustable working angle – for fuel saving and optimum cleaning efficiency
- Tried and tested variable cleaning track due to 3 roller types, each independently adjustable – for gentle handling of beets with maximum cleaning effect
- A total of 18 wear-resistant rollers with automatic reversing function – for perfect cleaning
- 140 mm roller diameter – for reduced wear, without sticking
- 9.50 m pick-up width – for efficient use
- Low speed with high loading efficiency – for lower fuel consumption
- Sliding wedge with replaceable tip and divided hood – for easy maintenance
- Pendulum equaliser on clamp blade– for optimum pick-up of remaining beets
- Automatic folding can be activated at the touch of a button– for fast working without getting out of the cabin
- All cleaning rollers optionally heat-treated with double build-up hard metal welding – for maximum durability
- Optional water spray system up to 1100 litres (continuous operation, interval, in case of hydraulic pressure, separate preselection of spraying and non-spraying intervals, switching right/left) – for cleaning without compromises
POST-CLEANINGTHE RIGHT CLEANER FOR EVERY OPERATION.
Different soils, different cleaning methods: Always clean crops perfectly with the unique, perfectly-aligned HOLMER cleaning hybrid of the VarioPick and post-cleaner versions, connected with each other via a web section with suspension. HOLMER exclusively provides four different post-cleaners, which can easily be changed. Whatever the soil, the perfect combination of cleaning and gentle beet handling is guaranteed.
TRANSFERECONOMIC VIABILITY MEETS CONVENIENCE.
Difficult to access loading areas, long distances to be bridged, considerable variations in loading heights: Thanks to the transfer loader with up to 15 metres transfer scope and a transfer height of over 6 metres, a loading angle of 332 degrees can be covered via two hydraulic slewing rings. The unique HOLMER DynaFill fully automatically controls in an innovative and intelligent manner the filling of the transport vehicles through laser sensors – a huge relief for drivers and those responsible.
- HOLMER DynaFill – for fully-automatic, even filling of the transport vehicles
- Lightweight construction – to reduce wear and costs (with highly robust PE)
- Optional with belt weigher integrated into the terminal (weighing cells, speed sensor, angle sensor, weighing computer) – for highly accurate beet quantities
- Optimally-positioned weighing rollers on the straight articulated section – for optimum weightning
Comfortable, safe driving with optimum balance: from the attachment of the pick-up via the wheelbase, right up to the hillside compensator system and the foldable tank, HOLMER has provided a complete solution for the field and the road.
- Up to 40 km/h on the road – for fast relocation
- The fastest automatic folding system on the market – for operation without delay
- Hillside compensator system – for good stability
- Suspension system – for safe driving on the roads
- Ideal weight distribution – through the ideal arrangement of modules
- Two braked drive axles – for maximum safety
- Hydraulic suspension 3rd and 4th axle – for maximum driving comfort
- Foldable tank for weight distribution – for optimum stability even in case of large transfer widths (without locking mechanism and software)
- Easily accessible and rapidly-folding tank – for fast fuelling and swift implementation
Retain an overview around the clock, and work in a relaxed atmosphere: the largest cab available on the market unites perfect safety and working comfort with its floor-level, domed windscreen. The workplace with thermal insulation glass provides the optimum all-round view.
- Auxiliary heating and air conditioning in the standard model – for an optimum working climate
- Driver-orientated operating elements – for ergonomic work without fatigue
- Pneumatically locked rotary heated seat – for maximum driver comfort
- Electrically adjustable and heated rear-view mirrors – for an optimum viewing angle
- Optimum sound insulation – for relaxed work
- Radio with hands-free talking function – for an optimum connection
- Spacious refrigerator box – for optimum supply
- Follow me home function on working lights – for a safe descent
- Working lights in LED design each with 2500 lumen power – for a pleasant working climate and maximum safety
- 4 Xenon headlights are optionally available for an optimum view
- 12.1 inch HOLMER EasyTouch-Terminal – for a clearly laid-out display
- 2 proportional comfort joysticks – for ergonomic work
- 4 cameras: video-monitored depth guidance with post-cleaning, wide-angle camera on the transfer loader and rear view camera – for safe machine monitoring
- The fastest automatic folding and unfolding system on the market – for a rapid working process
- On-board vehicle diagnosis – for fast assistance
- 3 individual cleaning positions can be saved – for maximum relief of strain on the driver
HOLMER EasyTouch
Always clear: The menu interface adapts to the operating mode – unrequired functions can be masked.
The high-quality hydraulic components of the Terra Felis 2 guarantee operational safety. In this way, a reduction in operating costs due to low-wear modules is guaranteed.
- 354 PS (260 kW) MTU engine with twin-turbo – for maximum power
- Level 4 final emission level with SCR technology (AdBlue) – for minimal exhaust emissions
- Loading operation in optimum engine range at only 1300 rpm – for efficient power transmission
- Revised drive concept – for road travel at 40 km/h
- HOLMER EcoPower – for optimum power with minimum fuel consumption
- Load-sensing hydraulics – for a good degree of efficiency
- Closed hydraulic circuits with high power reserves – for optimum power efficiency
- Optimised accessibility of the individual components – for maximum ease of maintenance
- Hydraulically driven and automatically reversing fan - for cleaning the cooling system
- Hydraulic tank integrated into the engine compartment to keep it warm over long periods of time through the residual engine warmth – for optimum oil viscosity even in very cold operating conditions
