Rika - Model RK200-02 - PAR Sensor
The RK200-02 PAR Sensor is mainly used for measuring solar radiation within 400~700nm wavelength. It is easy installation and can work continuously in all weathers. When there is sunlight, voltage output proportional to incident light intensity will be generated by the silicon-photo detector in the sensor. Its sensitivity is proportional to the cosine of incident light direct angle. Each product is with one sensitivity coefficient respectively. It can directly output radiation value in unit of μ*mol/m2*s.
Most popular related searches
PAR sensor
crop growth monitoring
crop growth
greenhouse control
crop research
crop monitoring
agrometeorology
research greenhouse
greenhouse construction
0-2000mV
- Range:0-2000W/m 2 PAR values(W/m 2 )= Voltage output value(μV)/1000
- Range:0-2500μ*mol/m 2 *s PAR values(μ*mol/m 2 *s)= Voltage output value(μV)/160
4-20mA
- Range:0-2000W/m 2 PAR values(W/m2)=(I(μA)-4000μA)/0.8(Where I is output current value,unit:μA )
- Range:0-2500μ*mol/m 2 *s PAR values(μ*mol/m 2 *s)= (I(μA)-4000μA)/6.4(Where I is output current value,unit:μA )
RS485
- MODBUS-RTU
- Agrometeorological research
- Crop growth monitoring
- Ecological research
- Environment surveillance
- Greenhouse control
- Metal construction
- Harsh environment workable
- High sensitivity
- No power supply measurement
- Compact size for easy use
