Swing Max - Power Hitche
The Swing Max will reduce your labour and equipment cost by baling twice as much hay with one less man and one less tractor. This system is designed to efficiently split your tractor’s existing PTO power into two so you can now operate an additional baler with the only one tractor. Simply put, Swing Max gives you more bales in less time.
Swing Max is mounted to your tractor via Cat 2 - 3 point hitch and PTO. Storage is made easy with heavy duty integrated legs that fold out of the way and allow quick safe hook ups.
The heavy duty pass through gearbox with a 1000 RPM input shaft and 540 RPM output shaft, delivers PTO power from your tractor to the first baler, The second baler is driven by hydraulic PTO motor.
The first baler follows the tractors path while the second baler is attached to the swing arm and controlled from in the cab. The swing arm’s wheeled dolly is controlled hydraulically giving you control in tight headlands and on the road.
One of the best parts of the Swing Max is that it will work with any baler and no modifications are needed. Just pin up, attach the PTO and plug in your hydraulics. Standard super bright LED lights are always ready for when the sun goes down.
Hydraulic remote couplers are located for both balers allowing you to control baler functions from the tractor.
The massive reach of the Swing Max boom (up to 42 feet) makes it a versatile tool in the field. When work is done Swing Max swings the second baler inline for easy single file travel. The steerable second baler dolly lets you take control of corners.
