AGROSAW - Model PC-2 - Pre Cleaner
Used for efficient cleaning of all types of seeds, grains, pulses, oil seeds etc.
-
Most popular related searches
Features:
- Robust machine of all steel construction
- Dynamically balanced aspirator fen
- Feed hopper equipped with feed control gate
- Specially designed nylon brushes to check sieve perforation clogging
- Stepless variable air controls
- Air chamber sieve deck assembly and spouts are self cleaning type
- Belt guard provided
- Sieve deck reciprocation provided by means of eccentric and connecting rods
Details
Working
Seed/Grain is fed into feed hopper from where it is sucked up by aspirator fan and dropped on the top sieve. Before falling on top screen, material is subjected to primary aspiration which drains off dust. chalT, straw & other light impurities, Material then passes through two sieve layers for separation according to width and th»ckness.Cleaned material again passes through air sifter and aspirator where the remaining light particles are sucked off bya strong upward draught of air; Final product and impurities are collected separately through discharge chutes.
Optional Sub-assemblies & Parts
AirTrunk, Surge &n. Feeding Elevator Dust Collector
