Macpenny - Precision Mist Jets
The result of extensive development and careful design, this atomiser jet is suitable for a wide range of uses. Precision made of brass, with a stainless steel striking pin. The jet is produced in four sizes to suit the individual bench width. The jet incorporates an 80 mesh filter capable of stopping even the finest particle from interfering in the nozzles operation. Each jet can be isolated from the rest of the system by inserting a rubber disc or similar under the striking pin and screwing down the adjusting nut.
Most popular related searches
- ½” BSPM thread
- 1m standard spacing for all nozzle sizes
- Operating pressure 3-4bar (satisfactory results can be achieved at a lower pressure)
- Jet output can be varied + or – 25% by adjusting the striking pin clearance.
- Nozzle Sizes:
- No.1 1m throw 15.9lph
- No.2 1.2m throw 27.2lph
- No.3 1.4m throw 36.4lph
- No.4 1.5m throw 54.6lph
