Miller STN - Model IntelliSpray 2 - Precision Spraying System for Agricultural Applications
The IntelliSpray 2 by Miller STN is an advanced spraying system designed for high precision and versatile agricultural applications. It features individual nozzle control, allowing for targeted spraying which ensures efficient use of resources. The system utilizes TeeJet stacked nozzle bodies that include a 3-way turret and a single straight-through nozzle, catering to high volume applications. Operators have the flexibility to choose between using the IntelliSpray 2 system or a conventional spraying system. The system supports a rate increase of up to 30% above target on eight nozzles and includes electrical disconnects at lift arms for easy boom removal. It has been rigorously tested for shock, vibration, impact, and weather resistance, and includes Viton seals that have undergone over 1,000 hours of testing for reliability. The IntelliSpray 2 is also IP69K rated, ensuring ease of cleaning and durability with severe-duty poppets coming as standard to extend operating life. This precision in turn compensation and instant on and off at nozzle bodies further increase its operational efficiency.Most popular related searches
What is IntelliSpray 2?
IntelliSpray 2 is a Pulse Nozzle System that maintains droplet size as the speed of the sprayer changes
–This results in better coverage
–Less drift as the speed of the sprayer increases
Available on all Nitro Sprayer Models
Standard Features Include:
- Individual Nozzle Control
- Turn Compensation
- TeeJet Stacked Nozzle bodies (3 plus 1). The nozzle body has a 3-way turret and a single straight through nozzle normally used for high volume applications. The Pulse Width Modulation Valve can be installed on either the 3-way turret or the single – operators choice. You have the ability to spray with the IntelliSpray 2 system or convectional spraying system – operators’ choice
- Rate increase of up to 30% above target rate on 8 nozzles
- Electrical disconnects at lift arms so you can still easily remove the boom
- Instant on and off at nozzle bodies
- Can spray conventionally
• IntelliSpray 2 maintains a constant droplet size by maintaining a constant spray pressure
–All chemicals have a recommended droplet size to do a accurate job of coverage
–Droplet size requirements are listed on the chemical label
–Droplet size is one of the criteria you use to choose your spray tips
• This is what normally happens on a conventional system
–You choose a spray tip to match your needs – Lets say:
• I want to spray at 14 mph
• I would like to run at 35 psi
• I would like to apply 15 gpa
• I need a tip that will maintain a medium droplet size
• As you speed up the pressure increases to maintain an accurate flow rate - Droplet size decrease or goes to a fine droplet size – Thus excessive drift occurs and you are off of the recommended droplet size
• If you slow down the pressure decreases to maintain an accurate flow rate - Droplet size increase or goes to a course droplet size – You have less drift but again you are off of the recommended droplet size
IntelliSpray 2 maintains a constant droplet size by maintaining a constant spray pressure
– Whatever speed you are going 8 mph or 15 mph the pressure will remain constant at whatever pressure you chose
– If the pressure stays constant the droplet size stays constant
• Thus doing a much better job of spraying
• Less susceptible to drift
• Maintaining droplet size requirements from the chemical producer
Turn compensation will control the output of the nozzles at different rates as you are turning
Example:
If you are turning to the right with a 120 foot boom
•The left tip is going significantly faster than the right tip
•The system will increase the nozzle out put on the left side of the boom and decrease the nozzle output on the right side for a more accurate application rate
IntelliSpray 2 has been tested for shock, vibration, impact and weather resistance in rugged terrain and extreme temperatures. Additionally, its Viton seals have had over 1,000 hours of testing to ensure system reliability. Intellispray 2 is also IP69K rated, meaning the NCV’s are pressure washer rated making it easier to clean. Severe-duty poppets now come standard, extending the operating life.
