Ecoline - Model W 200E-1135270 -PTO Drive Shaft For Tractor
FromCardan . Tec
The series Ecoline features the most affordable models equipped with Walterscheid technology. The series Ecoline is sized to fulfil simple drive requirements. It is, therefore, made up of components that are designed to meet these requirements. Many of the components built into the drive shafts of these series can be replaced for spare parts without a problem.
Most popular related searches
crop sprayer
fertilizer spreader
tractor
windrower
windrowing
tedder
fertilizer
windrow
windrow spreader
fertilizer sprayer
List of application:
- Small crop sprayers
- Artificial fertiliser spreaders
- Tedders
- Windrowers
- Dumper
Properties:
- Tractor side 1-3/8" (6) shaft collar kit
- Machinery side 1-3/8" (6) slide pin
- Lubrication interval 8h
- CE marking awarded
- Declaration of conformity
- Instruction manual
Technical information:
- Max. dynamic capacity 540 rpm20 kW (335 Nm)
- Max. dynamic capacity 1000 rpm31 kW (295 Nm)
- Values at a working angle of 5° and service life 700 hours
- A: 8x32x38
- B: 8x32x38
- Guard: SD 15
- U-joint: 24X61
- Profile: 0v/1
