- Cutting Width, 48″, 60″, 72″, 82-1/2″
- Overall Width, 53-3/4″, 66-1/2″, 79″, 85-1/2″
- Overall Length, 75″, 96″, 110″, 120″
- Approx. Weight, 460 lbs., 555 lbs., 645 lbs., 1,055 lbs.
- Blades, 1/2″ x 3″, 1/2″ x 3″, 1/2″ x 3-1/2″, 1/2″ x 4″
- Blade Carrier, Dish, Dish, Dish, Dish
- Blade Tip Speed (fpm), 9,992, 12,490, 14,989, 14,394
- Max. Brush Size, 1-1/2″, 1-1/2″, 1-1/2″, 2″
- Gearbox HP, 45, 45, 45, 80
- Gearbox Protection,
- Shear Pin (Slip Clutch Optional)
- Slip Clutch
- Drive Line Size #, Series 4, Series 4, Series 4, Series 6
- Deck Thickness (Ga), 11, 11, 11, 10
- Side Skirt Thickness (Ga), 11, 11, 11, 7
- Side Skirt Depth, 7″, 7″, 7″, 8″
- Wheels, Laminated Tires, Laminated Tires, Laminated Tires, Laminated Tires
- Number of Wheels, 1, 1, 1, 2
- Hitch Type, 3 Pt., Cat. I, 3 Pt., Cat. I, 3 Pt., Cat. I, 3 Pt., Cat. 2
- Tractor P.T.O. RPM, 540, 540, 540, 540
- Minimum HP Required, 20, 25, 30, 40
- Taper Splined Output Shaft Dia, 1-5/8″, 1-5/8″, 1-5/8″, 2″
- Safety Shield,
- Rubber Deflectors or Chain Guards
