John Deere
John Deere - Model 448 -Round Balers
FromJohn Deere
Regular pickup offers large feed opening and low-profile, mid-mounted pickup, MegaWide Plus pickup with MegaTough pickup teeth offers super capacity, Mechanical bale-shape indicators allow operator to make square-shoulder, dense bales easily, Vertical forming chamber, Staggered belt rolls with extra service life belt splices, Safety, Gate lockout, Built-in transport lights, Driveline, Constant-velocity PTO, PTO driveline holder, Pickup.
Most popular related searches
- MegaWide Plus pickup with MegaTough pickup teeth offers super capacity
- Regular pickup offers large feed opening and low-profile, mid-mounted pickup
- Forming chamber
- Vertical forming chamber
- Round bars on starter roll
- Staggered belt rolls with extra service life belt splices
- Mechanical bale-shape indicators allow operator to make square-shoulder, dense bales easily
- Twine system
- Twine wrapping (options)
- Double-twine hydraulic arm system
- Double-twine electric arm system
- Twine-cutting knife and anvil
- Twine storage
- Density-control system
- Hydraulic bale tensioning provides uniform bale density throughout the bale
- Monitor system
- Mechanical bale-shape indicators allow operator to make square-shoulder, dense bales easily
- Bale size
- Bale ejection system
- Bale ramp
- Tires
- 9.5L-14 tires
- High-flotation tires
- Wheel spindles
- Manufacturer: John Deere
- Model: 448
- Date of Specification
- Bale
- Size:
- Diameter, in. (cm): 35 to 51 (89 to 130)
- Width, in. (cm): 46 (117)
- Weight:
- Full-size bale in dry crop, lb. (kg): 750 (340)
- Max. allowable for silage bale, lb. (kg): 1250 (567)
- Baler
- Base Weight, lb. (kg): 3360 (1524)
- Weight, lb. (kg)*: NA
- *with wide pickup, net, bale ejection sys.:
- Length:
- Gate Closed, in. (cm): 135 (343)
- Gate Open, in. (cm): 174 (442)
- Height:
- Gate Closed, in. (cm): 92 (234)
- Gate Open, in. (cm): 114 (290)
- Width:
- With Standard Tires, in. (cm): 89 (226)
- With Opt. Tires (Hi-Flotation), in. (cm): 96 (244)
- Bale Forming
- Forming Chamber: Variable
- Belts-Other:
- Number: 6 Belts
- Strength: 3-ply
- Width, in. (cm): 7 (18)
- Length, regular, in. (cm): Two: 402.8 (1023)
- Length, staggered, in. (cm): Four: 410.2 (1042)
- Fabric: Nylon Polyester Combination
- Texture: Diamond Tread
- Enclosed % of Bale Surface: 91
- Belt Splices: Extra Service Life (wire-type) Clipper
- Density Control: Hydraulic, Isolated from Tractor
- Bale Size Indication: Visual Indicator & Audible Alert
- Regular Pickup
- Width:
- Inside, in. (cm): 46 (117)
- Flare, in. (cm): 56 (142)
- Drive: Roller chain w/ V-belt
- Bars: 4
- Number of Teeth: 72
- Tooth Spacing, in. (cm): 2.6 (6.6)
- Lift Control: Crank Std. - Hydraulic Opt.
- Gauge Wheels: Optional
- Stripper Diameter, in. (cm): 10 (25.4)
- Mega Wide Pickup
- Width:
- Inside, in. (cm): 61 (155)
- Flare, in. (cm): 71 (180)
- Drive: Roller Chains w/ Slip-Clutch
- Bars: 4
- Number of Regular Teeth: 80
- Number of Mega Teeth: 16
- Tooth Spacing, in. (cm): 2.6 (6.6)
- Lift Control: Crank Std. - Hydraulic Opt.
- Gauge Wheels: Semi pneumatic standard
- Stripper Diameter, in. (cm): 10 (25.4)
- Mega Tooth Pickup
- Width:
- Inside, in. (cm):
- Flare, in. (cm):
- Drive:
- Bars:
- Number of Middle Teeth:
- Number of Mega Teeth:
- Tooth Spacing, in. (cm):
- Lift Control:
- Gauge Wheels:
- Stripper Diameter, in. (cm):
- Twine Wrap
- Control: Operator Control
- Type: .
- Standard: Hydraulic
- Optional: Electric
- Twine Arms: 2 std.
- Twine Ball Capacity: 5 std.
- Monitor
- Monitor Console for Tractor: Not Available
- Gate Closed: None
- Bale Forming: Mechanical Indicators
- Bale Size: Mechanical Indicator
- Near Full Bale: Audible
- Full Bale: Audible
- Twine Arm Position Indicator: Mechanical
- Auto Wrap: Not Available
- Oversize Bale: Mechanical and Audible
- Surface Wrap
- Available: No
- Tire Size
- Standard: 9.5L-14, 6-ply
- Option 1: 31x13.5-15, 8-ply
- Drive Line
- Drive Protection: Shearbolt std. - Slip Clutch opt.
- PTO Speed: 540
- Type: Constant Velocity, Cat. 3 w/shearbolt; Cat. 4 w/slip clutch
- PTO Lockback Collar on Tractor Hookup: Option
- PTO 60-Degree Free Rotation: Option
- Tractor Requirements
- Minimum PTO, hp (kW): 45 (34)
- Hydraulic SCV Valves: 2 (hyd. Tie) - 1 (elect. Tie)
- High-Moisture Kit
- Silage Baler Features
- Starter Roll Scraper: Optional
- Powered Scraping Auger: No
- Spirals on Gate Roll:
- Pre-Cutter/Slicer: NA
