Hassela - Sawmills Industry Grapple
The Industry model has been specially designed for the sawmill industry, but can also be installed on other applications. Industry has three claws, for easy separation and grasping of single logs, industry features low profile design, it is wider and thus more stable, without compromising ease of operation.
-
Most popular related searches
Dimensions
- Max Working Pressure MPa 23
- Tip force, tip to tip kN 9,3
- Opening time at 70 l/min s 0,4
- Closing time at 70 l/min s 0,6
- Length, closed grapple mm 740
- Maximum grapple opening mm 1210
- Max width mm 397
- Height, closed grapple mm 310
- Height, closed grapple mm 510
- Height, open grapple mm 690
- Min load diameter mm 100
- Load area m2 0,15
- Max load Kg 3500
- Weight Kg 175
