Argiles - Model AFH5 - Self-Propelled Melon Harvester Machine

Kubota 1505 Engine, 26 HP 19KW to 2400rpm, Diesel cooled by water complying with the European regulations about pollution. Hydrostatic pto shaft. ·Reinforced differential at 1800 mm between centre of wheels ·Traction to the 4 wheels and 4 steering. Model of wheels can change depending on the required height. Wheel 15.0 X 55 -17” ·Parking brake with negative activation. · Tanks, oil and diesel fuel ·Total approximate size 7600mm long x 2550 wide x 3400mm high (the total length depends on chosen options) Harvesting Equipment: Conveyor belts with curved nerves Total working width 12.500 mm. Arm width 300mm Reception tray 600 x 1000mm to each exit of arms. Arms folding in 4 sectors (3 with hydraulic activation + 1 manual) Loading and unloading platform, individual working. 2000mm long, hydraulic folding and ¾ chain with wings. 5600mm long central platform with capacity for 4 crates, 3/4 chain without wings. ·Suncover in white PVC.
