- Road approval frame 25 Km/h with overall weight of 11 ton.
- Walking beam axle, bolted and ajustable for better load distribution.
- Hydraulic brake on all wheels.
- Wiring harness and parking brake are inside the main beam for better protection and difficult access area.
- 8 mobile bolsters, better life expectancy.
- Wide-size protection grid helps placing properly logs in the trailer safely.
- No operation needed for built-in lighting signs.
- Raised footbridge for crane operator: better visibility of the load and safety.
- Articulated drawbar +/- 32° with 2 hydraulic cylinders.
- Bolted ring or ball hitch.
- Forest crane 6750 or 8000 mm in option. With stabilization stand "flap down" type and multi-command controls.
- Size (L x W x H) 5840 x 2100 x 2040 mm
- Structure Single beam
- Beam dimensions (L x W x H) 180 x 180 x 6 mm
- GVW 11 ton
- Tare weight 2500 kg
- Loading length 3930 mm
- Ground clearance 517 mm
- Bolsters 8
- Articulated drawbar 2 hydraulic cylinders
- Drawbar angling +/- 32°
- Tyres 400/60 x 15.5 6TR TL
- Brake system Dynamic on 4 wheels, with 4 hydraulic cylinders, Ø 25 mm + static for parking brake
- Road approval Yes: 25 km/h
