Elho - Model NM 3700 F - Single Beam Front Mower Conditioner.
FromAb El-Ho Oy
World’s widest front mower conditioner. The ELHO NM 3700 F is the world’s widest single-beam front mower conditioner. With a cutting width of 3.7 metres, this model is extremely productive. The conditioner is also very effective at high speeds and in thick growth. The Pendulum Center System (PCS) enables the mower conditioner to move freely, while HydroBalance enables it to lightly follow the field surface. This helps prevent contaminants from being lifted into the forage and also reduces fuel consumption. The NM 3700 F front mower conditioner together with an NM 10500 butterfly mower conditioner is an extremely productive combination. Smart automation and GPS assistance also make it easy to use.
Most popular related searches
- Side lights kit
- Hydraulic kit for sideguards
- Hydrobalance top link Cat 2/3
- PTO shaft with share bolt
- Front bar
- Flat knife kit L+R (3,7 m)
- Adapter kit for large tyres
- Control cable
- Total length, m 4,2
- Width, m 2,5
- Height, m 2,7
- Bale diameter, m 1,0-1,5
- Oil flow l/min, min/max, 150 bar 20 - 60
- Pre-stretcher Alu, pcs x plastic width mm 1 x750
- Bale fork lifting power kg, 150 bar (with one lift cylinder) 1000
- Tyre size 26,00x12.00-12
- Weight, approx. kg 790
ELHO NM 3200 F:
- Pendulum Centre System (PCS) for the mowing unit, which allows it to move more freely
- Cutting unit is pulled from a point right above the front edge of the cutter bar
- In case of a collision, the cutting unit moves back and up (reducing the force of the impact by 50%)
- HydroBalance suspension
- Flexible suspension between the cutting unit and the load-bearing frame
