Greefa - Size and Long/Short Grading Machine

• Optical size sorting
  High resolution CCD infrared (black and white) cameras are used to determine the fruit size. Using a special combination of hardware and software, each fruit is measured several times, resulting in an extremely precise measurement.

• Long/short sorting

The optional programme long/short determines the length and diameter of the fruit. This makes it possible, for instance, to eliminate flat and elongated fruits.

Colour grading

Using a colour ccd camera system, the fruits are sorted on colour. The colour of the entire fruit is displayed.

Possibilities

• Number of colour groups varies per product and per machine
• Determination of average colour value, blush and background colour is possible

External quality (iQS)

iQS determines the external characteristics of a fruit. While the fruit rotates under the camera box, the cameras take till 60 shots. Software analyses these shots, and defects are projected onto a software model.

Possibilities

• External quality determination
• 2-10 lanes

• Suitable for CombiSort, EasySort, GeoSort, SmartSort and MSE
• 15 fruits per second per lane

Additional information

• High resolution cameras
• Shows boundaries of defect and analyzes these defects
• 100% food safe
• Very fruit-friendly
• Non-destructive

Internal quality (iFA)

iFA is a measuring system that analyses the internal characteristics and brix value of fruits. Physiological defects such as water core, storage defects and internal browning can be pinpointed without difficulty.

Possibilities

• Internal quality determination
• Determination maturity on stone fruits
• 2-10 lanes
• Available for CombiSort, GeoSort, MSE
• 8 fruits per second per lane

Additional information

• 100% food-safe
• Very fruit-friendly
• Non-destructive
