Worksaver - Model SSGB-8B - Skid Steer Grader Blade
FromWorksaver Inc.
The patented SSGB-8B Grader is designed to be used by asphalt, landscaping, and concrete flatwork contractors. The unit has an 8-foot, six-way hydraulically controlled moldboard operated by an in-cab remote.
Most popular related searches
- To help prevent damage, the moldboard is shear pin protected.
- Unit comes complete with 1/2” “connect under pressure” flat-faced hydraulic couplers and a reversible beveled cutting edge for long life.
- Optional laser system will maintain grade to tight tolerances.
- Optional End Plate Kit (Pair, #811980) and Laser Pole Kit (Pair, #812110) are also available.
- verall Height (in/cm) 46-1/2 / 118.1
- Overall Length (in/cm) 98 / 248.9
- Overall Width (in/cm) 95-1/2 / 242.6
- Weight (lbs/kg) 1195 / 542
- Mount Type Universal Skid Steer
- Hydraulic Blade Adjustments Tilt / Angle / Height
- Moldboard Width (in/cm) 95-1/2 / 242.6
- Moldboard Height (in/cm) 15 / 381 w/Cutting Edge
- Moldboard Width, Fully Angled (in/cm) 85 / 215.9
- Moldboard Rotation Left & Right 25 Degrees
- Moldboard Tilt Up or Down 25 Degrees
- Reversible Moldboard Cutting Edge (in/cm) 1/2 x 6 / 33 x 386 Double Bevel
- Moldboard Shear Pin Protection (in/cm) 5/16 / .8166 Diameter Shear Pin (Soft)
- 3 -Hydraulic Cylinders (in/cm) PSI/bar 2 / 5 Bore x 12 / 30 Stroke 3500 / 241
- Flat-Faced Couplers Included (in/cm) 1/2 / 13 Body - Connect Under Pressure
- Grader Control Valve Electric Solenoid Operated
- In-Cab Remote Control Standard
- Recommended Min. Skid Steer HP 45 HP (34 kw)
- Wheel Bearings Greaseable Tapered Roller
- Tire Size (in/cm) 18-1/2 x 8-1/2 x 8 / 47 x 21.6 x 20.3
- Product No. 811940
