Car-Tex - Model DAKOTA BP -Steel Slant Load Bumper Pull Horse Trailer

Standard FeaturesAvailable Sizes

• 2-horse, 14’ floor length w/2-3500# axles, 15” tires & 6-hole wheels
• 3-horse, 16’ floor length w/2-3500# axles, 15” tires & 6-hole wheels
• 3-horse, 16’ floor length w/2-5200# axles, 15” tires & 6-hole wheels

Dimensions

• 6’-6” body height
• 6’ or 6’-8” body width
• 30” tongue length

Undercarriage

• Rubber torsion axles with four wheel independent suspension and greasable hubs for easy lubrication
• Electric brakes on all wheels
• Radial tires on silver modular wheels with chrome center caps
• Spare tire rack in tack room

Coupler & Jacks

• 2-5/16” coupler and safety chains with hooks
• Top-wind jack with caster wheel
• Emergency breakaway system: switch, cable and battery box complete with battery and charger

Design Features & Hardware

• Low profile 6” radius corner galvanneal roof
• All steel frame with formed galvanneal panels
• Rubber mounted optical window in front
• 52” sides with air spaces above with plexiglass strap on both sides (plexiglass and rail not standard)
• Treated floor
• Steel hold backs on front tack door
• Drop leg rear gate stop
• Greasable exterior hinges
• Aluminum tread plate gravel guard on front and fenders
• Chrome trim with colored vinyl insert
• Pin striping
• Tag bracket

Stall Area Equipment

• Removable slant tubing dividers with solid head partition
• Quick release slam latches on all dividers
• One-piece rear door matches sides
• Interior and exterior tie rings

Lights

• DOT required lighting
• Dome lights (one in tack room and one in stall area)

Front Tack Room Equipment

• Front slant tack room (tack room size – 0’ to 4’-6”)
• Slant wall between stalls and front tack room
• Full front tack door with recessed locking handle located on curb side
• Clothes rod in tack room
• Four saddle racks on a tree and bridle hooks in tack room
