Agri King - Model KIRLOSKAR 3R810 NA2 - T44 -Tractor
Engine - Model: KIRLOSKAR 3R810 NA2. Type: 4-Stroke, 3-Cylinder, Di Diesel Engine. Power: 29.1kW/39HP. Rated Speed: 2,200 RPM. Aspiration: Naturally Aspirated. Bore Stroke: 96×112 mm. Displacement: 2,430 cc. Max. Torque: 144Nm. Air Cleaner: Dry Type. Cooling: Water Cooled. Homologation: Bharat (Trem) Stage III.
Most popular related searches
Clutch:
- TYPE: Dual Clutch (Optional)
- DIAMETER: 280 mm
Transmission:
- TYPE: Mechanical
- SPEEDS: 16 Forward + 4 Reverse
- CONFIG.: 4 x 2 x 2
- FROWARD: 1.8 – 30.7 Km/h
- REVERSE: 2.5 – 13.5 Km/h
- FINAL DRIVE: Epicyclic Hub Reduction
Steering:
- TYPE: Hydrostatic Power Steering (Optional)
- OIL SUPPLY: Through independent pump
Power Take Off:
- TYPE: 6-Spline
- SPEED: 540 RPM
- GROUND PTO: 163-2765 RPM
- RESERVE PTO: Available
Hydraulics:
- PUMP: Gear type
- DISCHARGE: 24 ltrs. per minute
- LIFT: Automatic Depth, Draft & Mixed Control
- LINKAGE: 3-Point, Category I
- CAPACITY: 1,500 kg at hitch point
Miscelaneous:
- BRAKES: Oil Immersed Disc Brakes
- PARKING BRAKES: Ratchet Type fully independent
- FRONT TYRES: 6.00×16 (8 PR)
- REAR TYRES: 13.6×28 (12 PR)
- TURNING RADIUS: 3.7 mtrs.
Dimensions:
- BALLASTED WT.: 1,980 kg
- TOTAL WIDTH: 1,720 mm
- WHEEL BASE: 2,040 mm
- TOTAL LENGTH: 3,628 mm (Front Hook to Lower Link)
Optional Features:
- Side Shifting Gear Levers
- Differential Lock
- Front Bumper
- Custom Colour Paint
- Heavy Duty Rear Axle
- Adjustable Front Axle
- Ballast Weights
