Moresil - Model Buggy Magnum -Tree Shaker Machine
The Magnum multi-purpose vehicle has been designed to perform all necessary tasks in the harvest of olives, nuts and fruit trees (almonds, pistachio, apples…) ensuring a profitable exploitation. The machine stands out for its great agility and manoeuvrability on the ground thanks to a hydraulic high performance and reliability based on the experience gleaned by Moresil. It has a Deutz engine with 120 HP and hydrostatic transmission with 4 wheel drive with independent pumps for each axle. We use hydraulic components from high reliable brands such as Danfoss, Poclain, Parker, etc.
Power
Features the electronically operated 120 hp Deutz engine, showing strength while reducing consumption by over 30%.
Versatility
It is a very versatile vehicle, as it can be fitted with different accessories in addition to the vibrator: stalk cutter, and processing and collection tank.
High performance
Thanks to its manoeuvrability and convenient joystick control, exceptional results are achieved.
Excellent vibration
With its double-cylinder vibrator, mid-engine, and variable pressure plate, it achieves an extremely high fruit knockdown rate.
The control panel controls easily the machine depending an the operation made. It shows information about the status of the machine and save past values to evaluate them.
The electrical system is greatly simplified because of the use of CAN Bus data transmission technology. Its high maneuverability allows to increase the job performance.
It has a telescopic arm with quick connectors to make faster the exchange of different accessories.
The Magnum multipurpose chassis is made of high strength steel.
Thanks to the joystick all the movements are controlled smoothly in a comfortable way.
Different attachments can be adapted quickly to perform all the duties needed in an olive grove which guarantees the profitability of the operation.
The Magnum multi-purpose vehicle is equipped with a shaker, which can vibrate trees with trunks up to more than 50 cm in length. It has the capacity to vibrate in both directions and can vary the vibrating speed. It has maximum manoeuvrability thanks to its multiple movement adjustments.
Shaker Models
- Models that adapt to different plantations:
- MV200: Max opening of clamp: 400 mm.
- Recommended trunk diameter: up to 200 mm.
- MV350: Max opening of clamp: 500 mm.
- Recommended trunk diameter: up to 350 mm.
- MV500: Max opening of clamp: 700 mm.
- Recommended trunk diameter: up to 500 mm.
- Vehicle Lenght: 3500 mm
- Vehicle Width: 1870 mm
- Vehicle Height: 1910 mm
- Power: 120 CV
- Wheel Drive: 4
