Countrywide - Model 8 - 4 Series -Triple-Flex Tandem Disc Ploughs

FromCountrywide Industries Pty Ltd

SHARE

Walking wheels on centre frame 84-92 plate. Aircraft tyres + 90mm axles - 8 stud. Large 219mm spools for heavy applications.

Most popular related searches

Discs: Front 28" x 8 mm all round/optinal 30"
Tyres: 305 x 19.5 Super Single truck tyres Up to 76 plate, 80-92 plate super single truck tyres or aircraft tyres
Gang Bolts: 2" diameter all model (H/T)
Bearings: Protected greasable gang bearings with triple lip seals
main Frame: 200 x 100 x 9mm RHS, Laminated with 20mm plate
Disc Weight: Approx 190 to 205kg per disc
Stub Axles 6 stud 75mm up to 76 plate - 90 Ø stud 80-92 plate

Gang angles independently adjustable
9" spacings
Hydraulic leveling cylinder
Discs spacers reduced diameter 4" more disc wear with increased soil and trash flow
Equal side loading on all gang bearings Roll out gangs
Bearing hangers of slim design Pressed from hi - tensile steel
Bolted stub axles with triple lip seals and dust covers
