Streumaster - Model SW 12/16 MA -Truck Mounted Spreaders

• Ideal machine for soil stabilization
• Machine for large-area, high capacity spreading of binding agents
• The binding agent is distributed by a big-dimensioned, hydraulically driven spreading auger
• The spreading quantity can be conveniently adjusted by hand or semi-automatically

The most important data:

• Container capcity: 12m³ (2-axle truck) or 16m³ (4-axle truck)
• Filling connector: 3” or 4”
• Spreading quantity 5 – 35 l/m² at 2 km/h
• Working width: 2.500 mm

• Standard coating ¦ ¦ ¦
• Special coating ? ? ?
• Binder container with internal reinforcement ¦ ¦ ¦
• Lockable side doors ¦ ¦ ¦
• Inspection ports with safety switch ¦ ¦ ¦
• Storage compartments ? ? ?
• Loading and lashing lugs ¦ ¦ ¦
• Built-up unit for 2-axle truck ¦ – –
• Built-up unit for 3-axle truck – ¦ –
• Built-up unit for 4-axle truck – – ¦
• Sub-frame for the carrying vehicle ¦ ¦ ¦
• Relief cover on the conveyor chains to prevent material building upin the container ¦ ¦ ¦
• Vent pipe and pressure relief flap integrated into the container ¦ ¦ ¦
• 3” pneumatic filling device on both sides ¦ ¦ ¦
• 4” pneumatic filling device on both sides ? – –
• 4” high-speed pneumatic filling device on both sides ? ? ?
• Hydraulic slide gate ¦ ¦ ¦
• Sensor-controlled conveyor chain ¦ ¦ ¦
• Mudguard with mounting parts *4 ? ? ?
• Lateral protection *4 ? ? ?
• Closed on-board hydraulic system ¦ ¦ ¦
• Oil flow control valve ¦ ¦ ¦
• Hydraulic system grouped together in a valve block for easy servicing ¦ ¦ ¦
• Electronic weighing device *1 ? ? ?
• Speed sensor mounted on the universal joint shaft ¦ ¦ ¦
• Central control electronics in a control cabinet ¦ ¦ ¦
• Control unit ¦ ¦ ¦
• Infinite adjustment of the quantity to be spread ¦ ¦ ¦
• Level indicator “Container full” or “empty” ¦ ¦ ¦
• Auxiliary engine for operation independently of the carrying vehicle or tractor ? ? ?
• Spreading screw with “RotoPlus” dosing device ¦ ¦ ¦
• Working width divided into 2 part-widths ¦ ¦ ¦
• Standard warranty ¦ ¦ ¦
• Customized warranty ? ? ?
• Dust protection ¦ ¦ ¦
• Access ladder ¦ ¦ ¦
• Bag filter package ? ? ?
• Automatic dust-collecting filter system ? ? ?
• Monitor system for monitoring the rear working area ? ? ?
• Lighting package with 4 LED working lights ? ? ?
• German TU¨V approval (Technischer U¨berwachungsverein =Technical Inspection Agency) *3 ? ? ?
• Collecting pan and digital suspended scales for checking the spread quantity ¦ ¦ ¦
• Safety certificate by the employers liability insurance association ¦ ¦ ¦
• Technical documentation in duplicate ¦ ¦ ¦
