TerraSolid TerraStereo - Sophisticated Visualization of Very Large Point Clouds

• Visualize up to 50 billion points that are organized in a TerraScan project
• Perform visual analysis and quality check in both, small- and large-scale displays
• Navigate through the point cloud freely or based on TerraScan trajectory files
• Create animations
• View laser data in stereo mode and create stereo screen captures
• Combine different visualization channels to improve the perceptibility of objects in the point cloud
• Switch point classes on/off
• Apply elevation exaggeration to the point cloud for specific analysis tasks
• Measure distances within the point cloud
• Digitize line vector elements and export them to TerraSurvey

Easily change between different display channels and point rendering modes:

• elevation, intensity and class coloring
• color by RGB values
• shaded surface display
• point density coloring
• TerraZ rendering method for masking foreground objects
• different quality levels for point rendering

There are some specific hardware requirements and recommendations in order to run TerraStereo in a proper way:

• minimum of 4 real processor cores, more than 4 are recommended
• > 16 GB of RAM
• > 8 GB of GPU memory recommended
• display device that supports quad-buffered stereo display (for stereo viewing)
  • stereo display or projector using DisplayPort or Dual-DVI connection (not HDMI)
  • (optionally) active or passive stereo glasses

TerraStereo for CAD requires a two-screen passive stereo system with a side monitor (no switching glasses possible).

GPU board used with TerraStereo must be NVIDIA® CUDA™ Compute Capability 5.2 or higher. In two GPU systems the primary (OpenGL) GPU can be older, if the other designated CUDA™ board meets the specs.

• Low-cost solution (low performance, mono display only):
  one high-end GeForce® board + standard monitor
• Basic solution (good performance):
  one high-end Quadro® board for example RTX5000 or more powerful one
• Recommended solution (best stereo quality and performance):
  PluraView 4k StereoDisplay + TerraStereo workstation (http://www.3d-pluraview.com/en/)
