Easy Lift Cradle System for bags up to 330 feet long. Minimized labor to install the bag. Reduced number of operators. Steady flow bagging perfomance: 700 ton / hora.  Tunnel for bags of : 9 feet. Power required: 60 HP. Tube / Auger Diameter: 400 mm / 16 9/64 in. Heavily reinforced horizontal auger. High capacity reception hopper. Heavy-duty frame built with shaped tubes and stamped sheet. Transmission through a chain and heat-treated gears. User-friendly mechanical height adjustment. Rubber flap that prevents grain spillage. Electrostatic polyurethane paint. Sliding hydraulic pan. Hydraulic Brake. Easy to adjust. Precise system. Tires : 7.50 x 16.

Hydraulic tray to fit the bag with ease. Electric Winch. Easy to operate and precise hydraulic brake system. Hydraulic operated pan. 400/65 – 15.5 Tire size. Biggest Hopper on the market: 9 ¼ x 6 ½ x 4 ¼ (LxWxH) 1400 US gallons. 20 inch Auger. 32000 bu/hr capacity (bagger only). New revolucionary easy to lift bag cradle. Heavy constructed frame. Can fit a 330 foot long bag by 10 foot diameter. Auger kit for Televeyor available. (Optional equipment).

Easy Lift Cradle System for bags up to 330 feet long. Minimized labor to install the bag. Reduced number of operators. Steady flow bagging perfomance: 700 ton / hora. Tunnel for bags of : 9 feet. Power required: 60 HP. Tube / Auger Diameter: 400 mm / 16 9/64 in. Heavily reinforced horizontal auger. High capacity reception hopper. Heavy-duty frame built with shaped tubes and stamped sheet. Transmission through a chain and heat-treated gears. User-friendly mechanical height adjustment. Rubber flap that prevents grain spillage. Electrostatic polyurethane paint. Sliding hand operated pan. Hydraulic Brake. Easy to adjust. Precise system. Tires : 7.50 x 16.

Easy Lift Cradle System for bags up to 330 feet long. Minimized labor to install the bag. Reduced number of operators. Steady flow bagging perfomance: 700 ton / hora. Tunnel for bags of : 9 feet. Power required: 60 HP. Tube / Auger Diameter: 400 mm / 16 9/64 in. Heavily reinforced horizontal auger. High capacity reception hopper. Heavy-duty frame built with shaped tubes and stamped sheet. Transmission through a chain and heat-treated gears. User-friendly mechanical height adjustment. Rubber flap that prevents grain spillage. Electrostatic polyurethane paint. Sliding hydraulic pan. Hydraulic Brake. Easy to adjust. Precise system. Tires : 7.50 x 16

Unloading performance: 360 ton/h. Power required: 75 HP. 9-feet bags. Tube/auger diameter: 400 mm. Horizontal auger diameter: 260 mm. Bottom angular gearbox and grain pusher: simplify the augers´performance and ensure and optimized way of ending the bag. Independent hydraulic controls. Hydrostatic movement: The machine moves automatically as the bag is winded up by the roll. The speed of movement can be adjusted. Single operating and transport position. Auger configuration specially designed for tough grain. Tires: 215/75-15´´. Electrostatic Polyurethane Paint. It compiles with the agricultural machinery safety standard IRAM 8076.

Unloading performance: 280 ton/h / 10,300 bu/h. Power required: 90 HP. 9-feet bags (with option to 10 feet). Tube/auger diameter: 430 mm / 17 in. Horizontal auger diameter: 250 mm / 9 ¾ in. Bottom angular gearbox: It simplifies the augers performance and ensures and optimized way of ending the bag. Independent hydraulic controls. Hydrostatic movement: The machine moves automatically as the bag is winded up by the roll. The speed adjustmen system and sturdy reduction gearbox. Auger configuration specially designed for tough grain. Tires: 265/70R16. Electrostatic Polyurethane Paint.

Heavy constructed sturdy trailer with hot-dip galvanized process to prevent corrosion for a long period of time. Adaptable body on AKRON chassis or truck. (Ask your dealer about truck feature availability). Maximum load: 20 to 30. Cargo volumen without compression: 35 to 40 cubir meter.
Cargo volumen with compression: up to 60% higher (depending on grass silage type and conditions). Horse power requirement: 140 to 160
Sliding Tandem or Tridem axles. Tandem axle has one fixed axle and one steerable axle. Tridem axle has front and rear steerable axles and a fixed center axle. Both versions can lock the steerable axles for backing up the unit. Tires: 600/50-22,5. Leaf spring suspension. Brake System (Optional). Side panel Height: 6 9/16 feet (left and right side). Foldable 500 mm panel (Optional).

Easy operation with its new and compact design. Minimum turning radius. Great unloading Speed: 10,000 and 13,000 Kg / minute (according to model). Great loading capacity assured by AKRON: 37,000 liters / 31,000 liters / 29,000 liters. Unloading tube: 500 and 600 mm diameter (according to model). Sliding bottom doors that speed-up and/or interrupt the unloading process and facilitate cleaning. Optional feature: scale for an accurate weight. Electrostatic polyurethane paint. Large toolbox. Rims for 23.1-30 / 24.5-32 tires. Optional feature: Heavy-use kit.
