The BACCO 1000 is an extremely compact trailed Drift Recovery multi-row sprayer. The conformation of the shields and relative supports has been developed in such a way as to obtain the maximum recovery of the drift of the product. BACCO can also be equipped with a patented system that mixes the plant protection product as needed keeping clean the water inside the main tank.

The OVS sprayer employs a patented system to maximize the effectiveness of the phytoiatric treatment. The two conveyors can be tilted independently and make this machine suitable for all types of vineyards or orchards, even on terraces. Thanks to two specially designed propellers (one in each conveyor), the airblast is powerfull and equally distributed on both sides of the machine.

The OVS sprayer employs a patented system to maximize the effectiveness of the phytoiatric treatment. The two conveyors can be tilted independently and make this machine suitable for all types of vineyards or orchards, even on terraces. Thanks to two specially designed propellers (one in each conveyor), the airblast is powerfull and equally distributed on both sides of the machine.

The PSV spray tower airblast atomizer has been designed for the homogeneous distribution of product along the row height and perfectly balanced on both sides of the machine. The tower reduces the distance-to-target. As a result, it is possible to reduce the spray output while improving his overall coverage! That represents considerable cost savings and reduced environmental impact. The conveyor of the PSV creates an “air blade” directed toward the tree-row with minimum loss of product by drift. Left/Right air flow divider on request.

Thanks to the axial propeller from 800mm, this tower sprayer develops a powerful air blast that easily penetrates even the thickest vegetable wall. Towers move the air and nozzles closer to the target compared to the curved booms on a conventional airblast sprayer. When the distance-to-target is reduced, the odds of droplets reaching the target are improved. That means less pesticide drift and more deposit in the plant canopy. Ideal for espalier and sapling plants, even with heights over 4 meters. The jets are adjustable and positioned outside the airflow.

Hot dip galvanized frame. The polyethylene tank internally is highly smooth, this avoids deposits and encrustations. Suction filter with connection for tank loading. Total emptying valve. Safe ladder with handles and pedestal. The boom lifting system is stabilized thanks to a “C” shape section guide. Mounts Colibrì booms (12 or 13 m) and Gabbiano booms (12 or 15 m).

 Reinforced and hot dip galvanized frame. The  polyethylene tank internally is highly smooth and avoids deposits and encrustations. Hydraulic lines and water hoses are neatly organized and protected by the reinforced plastic cable track. Suction filter with connection for tank loading. Total emptying valve. Safe ladder with handles and pedestal. The boom lifting system is stabilized thanks to a rhomboidal profile guide. Mounts Colibrì (12, 15 and 18 m) and Albatros (15 m) booms.

Reinforced and hot dip galvanized frame. The polyethylene tank internally is highly smooth, this avoids deposits and encrustations. Suction filter with connection for tank loading. Total emptying valve. Safe ladder with handles and pedestal.
Hydraulic lines and water hoses are neatly organized and protected by the reinforced plastic cable track. The boom lifting system is stabilized thanks to a rhomboidal profile guide. Mounts Colibrì (12, 15 and 18 m) and Albatros (15 m) booms.
