Harbin Dadi Biology Organic Fertilizer Co.,Ltd. products

Model: KHL-800. Capacity: T/h: 7-9. Raw material moisture content required: %: 30-35. Feed material particle size required (mm): 0.3-0.5. Pellet. rate:%: >90. Voltage : V 380. Pell, dia.: MM 3.5-5.5. Power: KW 160-180. Total weight: Kg 7000. Size: mm 6500-3800-2000.

Capacity: (T/H): 3-5-6 t/h. materials particle size:(mm): 0.3-0.5. Power: KW: 123 kw.

Organic Fertilizer Round Ball Granulator. Capacity : (T/H) 1-1.8 t/h. materials particle size:(mm) 0.3-0.5. Power: KW 37 KW.

Capacity :(T/H) 1-2. materials particle size:(mm : 0.3-0.5. Power: KW 30. Rotary Drum Dryer adopts slightly tilted drum which can be rotated. The wet materials are sent to hopper of rotary drum by belt conveyor or bucket elevator at from the higher side. Well-dried materials are collected from the other lower side, and then hot air enters the drum from the feeding side to the discharging Burning the coal gas oil in the Combustion Chamber (Boiler) . with making the dry hot wind . The dry hot wind goes though the chamber of rotary drum dryer under the action of induced fan . The combustion chamber (boiler) will need to built by buyer.

Rotary Drum Cooler adopts heating exchange method to cool materials. It is equipped with welded steel spiral scraping wings in front of the tube. lifting board at the end of the rotary body, and auxiliary piping system in the feed end of the cooling machine. The belt and pulley are driven by the main motor and through the reducer the drive shaft is put in motion. Rotary cooler is used for cooling fertilizer with certain temperature and particle size in fertilizer industry.

Semi-wet Crusher is a special equipment for crushing the materials with humidity and Multi-fibrous materials. It adopts high-speed rotating blades to ensure the feed materials nice granularity and high efficiency. Semi-wet material crusher is widely used in the organ: fertilizer producing process and it performs well in crushing chicken / cow / pig manure compost and other Semi-wet organic materials with moisture less t 20%.

The fertilizer packing machine consists of automatic weighing and packing machine, transport system, sealing machine and feeding machine. Feed bin also be equipped according to customers` demands. It is suitable for large-volume sub packaging of bulk materials, and is automatically weighed, conveyed and sealed in bags.

Capacity: (T/H) 2-2.5 t/h materials particle size:(mm) 0.3-0.5 Power. KW 15 KW.

Capacity : (T/H) 2-2.5 t/h materials particle size:(mm) 0.3-0.5 Power: KW 54.5 kw.
