Laird Manufacturing products

800 CUFT Mixing Chamber (7 FT Side Wall). %" Floor Thickness. Stainless Steel Liner on Floor (3mm). Two Vertical Augers with Stainless Steel on the Perimeter. Stainless Steel Cap (3mm) on the First Three Feet of the Leading Edge. Complete Hydrostatic System to Drive the Augers Engage 2-Speed and Opera Discharge Door. Plus One Controller. Two Heavy Duty Gearboxes (RR-3200) Complete with Poclain (MS-18) Hydraulic Motors. Large Discharge Door Located at the Rear of the Mixer.

1000 CUFT Mixing Chamber (61/2 FT Side Wall). %" Floor Thickness. Stainless Steel Liner on Floor (3mm). Two Vertical Augers with Stainless Steel on the Perimeter Stainless Steel Cap (3mm) on the First Three Feet of the Leading Edge. Complete Hydrostatic System to Drive the Augers Open/Close the Discharge Door. Plus One Controller.

Laird Manufacturing is in the business of manufacturing, selling and distributing equipment for the cattle feeding industry. Laird’s proven design, hydrostatic system, direct drive system, ruggedness and durability has made them a leader in the vertical mixer and feed delivery markets. Laird’s delivery boxes come in many sizes, from a small 1605 to a large 2807 for all your feeding needs. Laird’s delivery box works with a friction held, potentiometer joystick. This allows you to keep the joystick at optimum position for a consistent and even flow of feed. With the Trigger held and the joystick all the way back, the discharge conveyor will not move at all. With the joystick in the center it will work at 50%. Finally all the way forward will allow you to work at 100%.

7FT Wide Inside Side Walls (10ga) 3mm 7ga Floor Material WR-78 `Mac` Chain (2 Sets) with Tubing as Slats Fenders and Mud Flaps Cab Protector Steel Hydraulic Lines (4) U-Bolts for Mounting Drive Shaft (2 7/16`) Idler Shaft (2`) Single Beater Attachment (Hydraulic Drive) Guillotine Gate with 2 Cylinders Mounted on Box.

21 "Wide Belt Discharge. 7FT Wide Inside. 5FT Walls (6FT walls on model AC-1406). Discharge Belt Driven by Tractor PTO. Hydraulic Gear Box Driven Floor Chain Powered by Tractor. Manual Flow Control for Floor. Dual Apron WR78 Big Barrel Floor Chain with Double Center Adjustors. Hydraulically Driven Door. Single Axle with (2) 385/65R X 22.5 Super Single Tires Without Suspension. Paint - White with Blue Trim.

7 Ft. Width l-D.. WR-78 Dual Apron Chain with Tube Slats. 7ga Floor Material. Cab Protector. Dual Rear Drives on Floor. Steel Hydraulic Lines. Drive Shaft 2 7/16"/Idler Shaft 2". Hydraulic Vertical Beater Attachment. Guillotine Gate with 2 Cylinders Mounted on Box. Wet Kit for Beaters Driven by Tractor PTO. 2 Section Gear Pump (Pressure Compensated). Reservoir (70gal). Triple Axle with Spring Suspension with Forced Steering for Front and Rear Axles. Ball and Coupler Hitch. 6 X700/40-225 (18ply) Floatation Tires (16,970 Lb. Capacity). 6X22.5X24 Plate Wheels. Drawbar with 16,000 lbs Spring Pack. Hydraulic Brakes on All Axles (Supplied by Tractor). All Plumbing to Tractor. Painted White with Blue Trim.

10 ga Floor. 1/2" MDO. 2 7/16" Drive Shaft (1 Piece). 2" Idler Shaft. Stainless Steel Runners Under Chain. Front Panel Made from Expanded Steel. Dual Floor Drive (2 X OMS 80 with Auburn Gearbox). Triple Axle System with Forced Steering on the Front Axle and Rear Axle. (36T Capacity) (Hydraulic (Brakes included) on all Axles). Also included 2 Hydraulic. Cylinders for the Forced Steering Medium. Heavy Duty Chassis made from Tubing. Hydraulic Jack Stand Mounted on Drawbar. 6 X 700/40-225 (18 Ply) Flotation Tires (16,970 lbs Capacity). 6X22.5X24 Plate Wheels. Painted White with Blue Trim. Drawbar with 16,000 lbs Spring pack. Scharmiiller Ball and Coupler Hitch. WR-78 Chain (Big Barrel) with 2" Tubing (2X1X3/16"). 2 Hoses for Opening and Closing Rear Door. 2 Hoses for Operation of Hydraulic Floor.
