RECK-Technik GmbH & Co. KG products

The mixer model Tiger can be used in small pit openings (from about ø 60cm) due to the cranked folding frame. Attachment to the draft links and the tractor clevis. The insertion and height adjustment of the mixer can be operated through the tractors hydraulics from the seat. There are no hoist chains and manual spindles necessary. The height adjustable clevis bow allows a regular bending of the normal cardan shaft and an adjustment to the different circumstances and tractor sizes. There is no restless up and down of the slurry mixer during stirring up because of the twisting in the tractor clevis. The folding PTO mixer Tiger is available from 3,60m to 6,2m length (interim lengths are available on request).

The mixer model Gepard can be used even in bigger slurry pit openings (from about ø 80cm) due to the cranked folding frame. The attachment of the mixer is on the tractor’s three point linkage (draft link and upper link). The insertion and the depth adjustment can be done by the tractors hydraulics and the manual spindle. The Gepard mixer can be used as well for mixer shafts in closed circuits or slalom systems. The folding PTO mixer Gepard is available from 4,60 m to 6,60 m length (interim lengths are available on request).

The mixer model Jaguar can be used in small slurry pit openings (from about ø 60cm) due to the cranked folding frame. The attachment of the mixer is on the tractor’s three point linkage (draft and upper link). Easy and smooth insertion of the slurry mixer with the additional hydraulic cylinder, independent of the tractor’s hydraulic which is often inexact. A regular and even bending of the two universal joints of the standard cardan shaft is possible through the hydraulic cylinder and the tractor’s hydraulics. This allows operating with little wear on the standard cardan shaft. The folding PTO mixer Jaguar is available from 4,60 m to 7,60 m length (interim lengths are available on request).

The PTO mixers Typhoon are the robust ones with solid construction of frame, for open slurry pits and slurry lagoons. There are three different versions for selection: the standard version, the reinforced version the extra strong version. All Typhoon mixer are with long lasting ball bearing free special mounting of the drive shaft in the aggressive slurry - insensitive to leftovers, straw and animal hair.

The Typhoon more is the optimal PTO mixer for big slurry pits and lagoons. There are mixer length until 11,3m available. In order to stabilize the mixer tube, the PTO mixer Typhoon more is reinforced with a welded on triangle mast. Instead of dirt- sensible rolling bearings with seals which do rarely withstand the aggressive slurry for a long time (for example animal hairs) the Reck slurry mixers are equipped with the extremely resistant special slide bearings. They are long living, maintenance friendly and have proved very well over decades in the slurry sector.

Advantages of the Lagoona mixer: With the solid frame it is possible to drive in the lagoon with the mixer. Due to the adjustability of the axis it is possible to drive in the lagoon oblique. A regular and even bending of the two universal joints of the standard cardan shaft is possible because of the drawbar as standard.

With the swiveling mixer Hercules the company RECK offers a powerful mixing ability for tractors up to 300 Hp. Final disposals with maximum 1,5m height and large lagoons can be easily agitated from "one" position. The Hercules mixer can be swiveled hydraulically through 170° (left and right) from the tractor's seat. Narrow paths between large lagoons can be utilized for driving with the tractor to position the agitator to either side. Due to the large swivel radius, the surface crust can be mixed in several points and the slurry is homogenized more quickly.

Practical for slurry towers up from 1,50m above the ground level. The PTO tower mixer Mammoth can be used from 1,50m to 6,0m high slurry towers.

Practical for slurry towers up from 4,00 m above the ground level. Maximum flexibility due to the possibility of swivelling the mixing rod through max. 270° and to move out the tower up to maximum 6,00m.

Field of application: For Closed Circuits and Slalom Systems.
