H I - V I SFRONTLOADERTECHNICS FOR PROFESSIONALSTHE NEW GENERATION68STRONG ARGUMENTS FOR HYDRAC FRONTLOADERSFREE vIEWbetter view to the implements trough the new designed and advanced cross frameCOMPACT vALvE-UNITSincl. pressure limitation and flangeable electro valves (Single/Duo)SHOCk AbSORbER SDFpipe rotor in the cross frame for more driving comfort (everytime retrofit)vALvE TECHNICScentral, compact and protected by a cover plate bUCkET-qUICk DRAWDOWNwith floating position when pushing the button the bucket will quick drawdown the material.A combi function enabled the lifting and the concurrent drawdown of the bucket.EASILY ACCESSIbLEexterior greasing points in every bolt bearing with cover caps Bushes in all bearingsRESTS EASY TO HANDLEcomfortable handling in standing(hydraulically operating on request)qUICk CHANGE PLATE EUROhydraulic implement locking on requestACTIvE REAR AxLE SUPPORT active brackets parts provide a hub free of play from the brackets on the tractor and support the frame of the tractorHigh quality painting due to "2 - components painting technology"Great dumping angleAccurate parallel guidanceSafety cylinders for higher tilting speedSuperior bucket heelingstrong double acting cylinders with ball and socket joint bearingbUCkET CONICAL bucket conical with cutting edge high wear restistant HARDOXbRACkETS TECHNOLOGIEbETTER vIEWINNOvATIvE DESIGNNEW bRACkETS PROFILin fine grained steel assured best quality.LAYING OF THE HYDRAULIC mounted under the rocker arms: invisible, better protected, easier accessible.FINITE-ELEMENTIMPROvEMENThighest stability at least weightTHE PROFESSIONAL FOR CONNECTING AND DISCONNECTING IN A FEW SECONDS WITHOUT DISMOUNTING FROM THE TRACTORAUTOLOCk - this unique drive in system allows to attach and detach the front-end loader completely hydraulically by pressing a button and operating the control gear - without leaving tractor´s seat. Only in a few secondsThe advantage is the operating comfort, the time saving and also there is no risk of injury for the driver.No additional controller necessary.AUTOLOCkFULLY HYDRAULIC LOCkING SYSTEMall mechanical, electrical and hydraulical couplings are connected automatically.PRESSURE RETAINING vALvE integrated in the valve block prevents the fading of the tilting cylinders - also during high weights HYDRAULICALLY FOLDING UP OF THE RESTSthereby the loader can not descent because of mechanical locking mechanismvITEC AUTOLOCkè Attach and detach fully automatic in a few secondsè Without dismountingè Without additional controllerè Rapid movement cylinder and safety valve with locking valvesè Rests are folded up and down hydraulicallyè Rear axle support activeè Rocker in fine-grained steelè Pin support with bush and to greaseè Universal joint bearing on lifting cylinder (see type list)STANDARD EqUIPMENTOperating from the driver´s cabine Front-end loader AL 2000 AL 2100 AL 2200 AL 2200 xL AL 2300 AL 2300 xL AL 2500 AL 2500 xLTractor rating up to 70 hp 85 hp 105 hp 110 hp 140 hp 150 hp 200 hp 230 hpLifting height [mm] 3300 3550 3750 3900 4100 4250 4500 4700Tipping height [mm] 2370 2620 2720 2970 3170 3320 3570 3770Overhead loading width [mm] 700 750 800 800 900 900 1000 1000Scoop depth [mm] 150 150 150 150 150 150 150 150Lifting force at top (at 180 bars) [kg] 1500 1580 1700 1710 1965 2055 2540 2550Lifting force at bottom (at 180 bars) [kg] 1980 2000 2015 2000 2865 2600 2860 3000Dumping angle 63° 63° 63° 63° 63° 63° 63° 63°Scooping angle 46° 46° 46° 46° 46° 46° 46° 46°Diameter of cylinders [mm] 70/40 70/40 70/40 70/40 80/40 80/40 80/45 80/45Diameter of tipcylinders [mm] 70/36 70/36 70/36 70/36 80/40 80/40 80/40 80/40Weight [kg] 465 510 600 610 650 690 755 835Technical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.è Multi hoses couplerè Hydraulic tilting deviceè Rapid movement cylinder and safty valveè quick-change implement attachmentè Mech. parking supports on the rocker armè Stop cockè Parallel guidanceè Double acting lifting cylindersè Rear axle support (lsee type list)THE PROFESSIONAL WITH AUTOMATIC INTERLOCk ON THE bRACkETSRESTS EASY TO HANDLE comfortable handling in standing(on request hydraulically)SELF-CONTAINED CLOSINGthe hub is free of clearance because of the locking cam.vITEC EUROkIPP Series 2000EUROkIPP Series 2000 - the worldwide special drive-in system with patented, automatic and mechanic interlock on the brackets.On attaching the loader on the tractor the closings of the brackets lock automatically and so the tractors cab must left only one time.The driver must only leave the tractor´s seat one time to couple the hydraulic hoses and to fold up the rests. The same when you dismount the loader.EUROkIPP 20003rd or 4th function on request standard: label in tractor colourStandard: multi hose couplerOn request: with integrated electric connectorDRIvE IN - CLICk - READYthe mechanical locking system is working automatically. Front-end loader Ek 2000 Ek 2100 Ek 2200 Ek 2200 xL Ek 2300 Ek 2300 xL Ek 2500 Ek 2500 xLTractor rating up to 70 hp 85 hp 105 hp 110 hp 140 hp 150 hp 200 hp 230 hpLifting height [mm] 3300 3550 3750 3900 4100 4250 4500 4700Tipping height [mm] 2370 2620 2720 2970 3170 3320 3570 3770Overhead loading width [mm] 700 750 800 800 900 900 1000 1000Scoop depth [mm] 150 150 150 150 150 150 150 150Lifting force at top (at 180 bars) [kg] 1500 1580 1700 1710 1965 2055 2540 2550Lifting force at bottom (at 180 bars) [kg] 1980 2000 2015 2000 2865 2600 2860 3000Dumping angle 63° 63° 63° 63° 63° 63° 63° 63°Scooping angle 46° 46° 46° 46° 46° 46° 46° 46°Diameter of cylinders [mm] 70/40 70/40 70/40 70/40 80/40 80/40 80/45 80/45Diameter of tipcylinders [mm] 70/36 70/36 70/36 70/36 80/40 80/40 80/40 80/40Weight [kg] 465 510 600 610 650 690 755 835STANDARD EqUIPMENTTechnical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.THE PROFESSIONAL WITH DRIvE-IN FRAMECOMFORTAbLE MOUNTING AND DISMOUNTINGall operating elements (brackets-closing, rests) are reachable comfortable.RESTS MECHANICcomfortable handling in standing(on request hydraulically)EUROkIPP Series 1000 - a narrow but stable drive-in frame guarantees a clear view.Optimal load distribution due to 4 adjustable mounting points of the front-end loader on the brackets.A patented excentric quick-acting looking pin made from cast steel ST52 always assures a perfect fitting on the brackets. These professional front-end loaders are made especially for older tractor models.A NARROW bUT STAbLE DRIvE IN FRAME GUARANTEES A CLEAR vIEW.è Multi hose couplerè Hydraulic tilting deviceè Rapid movement cylinder and safty valveè quick-change implement attachmentè Mech. parking supports on the rocker arm è Stop cockè Parallel guidanceè Double acting lifting cylindersè Rear axle support (see type list)STANDARD EqUIPMENTEUROkIPP 1000vITEC EUROkIPP Series 1000SERIES 1000 WITH DRIvE-IN FRAME- FOR OLDER TRACTOR MODELS Front-end loader Ek 1000 Ek 1100 Ek 1200Tractor rating up to 70 hp 85 hp 105 hpLifting height [mm] 3300 3550 3750Tipping height [mm] 2370 2620 2720Overhead loading width [mm] 700 750 800Scoop depth [mm] 150 150 150Lifting force at top (at 180 bars) [kg] 1500 1580 1700Lifting force at bottom (at 180 bars) [kg] 1980 2000 2015Dumping angle 63° 63° 63°Scooping angle 46° 46° 46°Diameter of cylinders [mm] 70/40 70/40 70/40Diameter of tipcylinder [mm] 70/36 70/36 70/36Weight [kg] 465 510 600Technical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.è Automatic locking on the bracketsè Hydraulic tilting device with rapid movement cylinder è quick-change plate EUROè Parking supports on the frame assyè Lock off valve for lifting cylinderè Double acting lifting cylindersè Level display (implements) (rear axle support)è NEW on demand: Parallel guidance (Series EC 2000, EC 2100)RUN IN – CLINk – READYMechanical locking system is working automatically.SELF-CONTAINED CLOSINGThe hub is free of clearance because of the locking cam.ECONOMY Series 2000THE COMPETITIvELOADING POWERFUL – SAvING MONEY.è Manually locking on the bracketsè Hydraulic tilting device with rapid movement cylinderè quick-change plate EUROè Parking supports on the frame assyè Lock off valve for lifting cylinderè Double acting lifting cylindersè On demand: Level display (implements) (rear axle support)è NEW on demand: Parallel guidance (Series EC 1000, EC 1100)STANDARD EqUIPMENT EC 1000ECONOMY Series 1000STANDARD EqUIPMENT EC 2000COMFORTAbLE MOUNTING AND DISMOUNTINGAll operating elements (brackets-closing, rests) are reachable comfortable.FOR NEW TRACTOR MODELS SERIES 1000 WITH DRIvE-IN FRAME - FOR OLDER TRACTOR MODELSon request 3rd and 4th function on the crosstube Front-end loaderEC 2000EC-P 2000EC 2100EC-P 2100EC 2200Tractor rating up to 70 hp 85 hp 105 hpLifting height [mm] 3200 3450 3650Tipping height [mm] 2270 2520 2720Overhead loading width [mm] 700 750 800Scoop depth [mm] 150 150 150Lifting force at top (at 180 bars) [kg] 1320 1520 1680Lifting force at bottom (at 180 bars) [kg] 1740 1980 2000Dumping angle 63° 63° 63°Scooping angle 46° 46° 46°Diameter of cylinders [mm] 70/40 70/40 70/40Diameter of tipcylinders [mm] 70/36 70/36 70/36Weight [kg] 400 440 520 Front-end loaderEC 1000 EC-P 1000EC 1100 EC-P 1100EC 1200Tractor rating up to 70 hp 85 hp 105 hpLifting height [mm] 3200 3450 3650Tipping height [mm] 2270 2520 2720Overhead loading width [mm] 700 750 800Scoop depth [mm] 150 150 150Lifting force at top (at 180 bars) [kg] 1320 1520 1680Lifting force at bottom (at 180 bars) [kg] 1740 1980 2000Dumping angle 63° 63° 63°Scooping angle 46° 46° 46°Diameter of cylinders [mm] 70/40 70/40 70/40Diameter of tipcylinders [mm] 70/36 70/36 70/36Weight [kg] 400 440 520Technical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.Technical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.è Hydraulic tilting device with rapid movement cylinder è Double acting lifting cylindersè bracket work tableSeries MINITHE SMALL SIzED - POWERFUL AND EFFECTIvE. SERIES MINI - FOR SMALL AND COMPACT TRACTORS Front-end loader Mini 1 M2P-GR / M2P-RL M3P-GR / M3P-RLLifting height [mm] 2030 2200 2500Overhead loading width [mm] 400 700 650Scoop depth [mm] 100 100 100Lifting force at top [kg] 300 810 850Lifting force at bottom [kg] 435 950 1100Dumping angle 55° 55° 55°Batch breaking load [kg] 700 850 1020Scooping angle 40° 48° 48°Diameter of cylinders [mm] 35/50 36/50 36/60Diameter of tipcylinders [mm] 20/40 30/50 36/50Weight [kg] 100 210 290MINIè Parallel guidanceè Hydraulic tilting device with rapid movement cylinder è quick-change plate EURO (from Mini 3 Euronorm)è Double acting lifting cylindersè bracket work tableComplete equipment around the small tractorintegrated support legsSTANDARD EqUIPMENT MINI 1STANDARD EqUIPMENT M2P-GR / M2P-RL / M3P-GR / M3P-RLTechnical specifications are measured at the tool rotation and are dependent on system pressure, tire size and height of attachment. All data without guarantee. Information subject to change without prior notice. Attention: Only use original HYDRAC equipments. Only thereby you get an exact parallel guidance and the specified dumping and scooping angle.Functions:è Proportional control for up/down, implement move-in/dump out and additional functionsè Additional funcions: yellow button = 3rd oil circuit green button = 4th oil circuit black button = 5th oil circuitè Float position for the rocker (fixable)è Operating speed programmableè Flexible mountinggg joystick and custom positioning optionOptional equipment:è NEW: Device reset to saved equipment positionè Device dumpè Armrest (height and reach adjustable, folding upwards)è Up to two additional front switcher (like a remote control for raising and lowering the front linkage)The compact joystick enables the best control possibility with just taking two fingers.Due to the flexible mounting the operator allows to adjust the position of the joystick, depending on body size and position individually and continuously. If there´s no work with the frontloader, the joystick can be easily moved to one side.As an alternative version of the standard the joystick is also available with a comfortable armrest.Three push buttons allow to perform additional functions.Flexible mounting for joystickControl unit is also available with an armrestELEkTROPROPORTIONAL CONTROL UNIT "PROFI-CONTROL"Pressing a button and the bucket is determined by the gravity of the load and is automatically emptied.NEW: Automatic eset device to saved positionFULLY AUTOMATIC RESET DEvICE DEvICE DUMPMULTI-HOSE COUPLER TYPE "q" for direct coupling at the lateral mounted single-lever control device.Easy - Quick - SafeSHOCk AbSORbER SDFFor more comfort and security. The accumulator absorbs a great part of vibrations, resultant from fronloader operation.• switching on/off is possible mechanically or electrically• can also be retrofitted• only for series ViTec availableELECTRIC vALvE SINGLE OR DUO - FOR 3RD OR 4TH CIRCUITDuo: two additionally double acting functions (e.g. round bale gripper, silo cutting tongs)Possible to couple under pressure.Single: one additionally double acting function (e.g. round bale gripper, silo cutting tongs)MULTI-HOSE COUPLER TYPE "L"for direct coupling at the lateral mounted single-lever control device.Easy - Quick - SafeSINGLE-LEvER CONTROL Operated with Bowden cables.Up to 4 different operations canbe done with just one joystick.(4 double acting hydraulic circuits) AUTMATIC qUICk-CHANGE PLATEAUTO-ConnectAll electrical and hydraulical couplings are connected automatically.The implements are attached and detached without leaving the tractor´s seat.HYDRAULIC SWIvEL DEvICE FOR qUICk-CHANGE PLATEThe implement can be swiveld hydraulically to the left and to the right. Range: ±7°. (e.g. with a mounted snow blade for clearing the sidewalk - the blade can be swiveld back into horizontal position)HYDRAULIC IMPLEMENT LOCkINGDue to a hydraulic cylinder in the quick change plate, implements can be locked and unlocked form inside the tracor´s cabin trough operating buttons.Quick - Safe - ComfortableSINGLE vALvESHOCk AbSORbER FOR HIGHER DURAbILITYDUO vALvEACCESSORIES±7 °CAMERA-SYSTEM For better view and working unerring.IMPLEMENTSWidth Capacity Weight1,25 m 322 l 135 kg1,45 m 370 l 150 kg1,65 m 419 l 190 kg1,85 m 468 l 205 kg2,05 m 516 l 225 kg2,25 m 565 l 240 kgWidth Capacity Weight1,65 m 719 l 230 kg1,85 m 808 l 250 kg2,05 m 886 l 270 kg2,25 m 1205 l 315 kg2,45 m 1314 l 340 kg2,65 m 1412 l 360 kg Round bale gripper diameter of bale WeightRBG-180-M 95 - 180 cm 240 kgHighly wear-resistant cutting edge HARDOXRounded for easy filling and emptyingEdge for gradingadaptation EURO recording reinforced base plates for increased stabilityConical shape for better emptyingReinforcing bead for maximum stabilityEdge reinforcement for heavy duty applicationsDUNG FORk HYDRAULIC ROUND bALE GRIPPER with pressure retaining valveFor soft handling of round balesbUCkET FOR LIGHT MATERIALS CONICALSILAGE bUCkET GRIPPERhydraulically operatedPALLET FORk WITH HYDRAULIC CLAMPfor holding downROUND bALE FORk, MECHANICALFrame width: 1,40m PRONGS - FLAT - FOR USING AS A PALLET FORkPALLET FORkFrame width: 1,40 m Profile: 80 x 40 mmloading capacity 3 toPRONG - ROUND - FOR USING AS ROUND bALE FORkbUCkET CONICAL (with or without teeth) Welded teeth are flushed with the bucket base.IMPLEMENTSNEW BUCKET CONICAL with cutting edge- high wear resistant HARDOXWidth Teeth Weight1,25 m 7 teeth 135 kg1,45 m 8 teeth 155 kg1,65 m 9 teeth 170 kg1,85 m 10 teeth 185 kg2,05 m 11 teeth 200 kg2,25 m 12 teeth 215 kgWidth Capacity Weight1,50 m 650 l 370 kg1,70 m 740 l 390 kg1,90 m 820 l 410 kg2,10 m 950 l 430 kg2,30 m 1080 l 450 kgWidth Capacity Weight1,20 m 650 l 210 kg1,40 m 750 l 230 kg1,60 m 850 l 250 kg1,80 m 950 l 270 kg2,00 m 1050 l 290 kg2,20 m 1150 l 310 kgWidht Capacity Weight1,60 m 900 l 400 kg1,80 m 1000 l 450 kg2,00 m 1100 l 520 kg2,20 m 1200 l 570 kgbUCkET GRIPPER HYDRAULICUNI-GRIPPER TONGHYDRAULIC HIGH DUMPING UNITHYDRAULICLength of forks Weight1,00 m 130 kg1,10 m 139 kgFrame width Weight1,40 m 220 kgLength of forks Weight1,10 m 46 kgLength of forks Weight1,10 m 128 kgLength of forks Weight1,00 m 74 kg1,10 m 78 kgIMPLEMENTSWELD ON PLATESfor third-party implementsstraight (for pallet forks) bent (for buckets)3 POINT ATTACHMENT for the use of 3-point-implements on frontloaders (for transporting)LOAD HOOk integrated in quick-change plate endless rotable3 POINT COUNTER WEIGHTSfront and back counter weight500kg800kg1200 kg SNOW bLADE UNIvERSAL mechanic or hydraulichydraulic swivel device ± 30°3 POINT qUICk CHANGE PLATE for using loader implements on a front or rear linkageREAR CONCRETE bALLAST WEIGHTSfor using at the rear HYDRAULIC SqUARE bALE TONGS QBZ 2000 hydraulically operatedFor 60 cm to 200 cm widthIMPLEMENTSHYDRAULIC WOOD TONGSwith rotator and 500 mm armsTOLLS FOR ROLLING/MOvING CUT with hydraulic holding-down clamp bIG bALLER Max. loading: 1000 kgWidth: 1,33mHeight: 1,48mSILAGE CUTTING TONG hydraulicallyè Opening width 90 cm è 2 hydraulic cylindersè Seperated, screwed changeable knivesè Extra small distance of the spikes (especially for silage made of corn)è Closed cutting unit provides an optimal stabilityè No exposed bearing (especially designed for concrete walls of the siloè On demand: Automatically dischaarging by pushing-off-system Silage cutting tong Width Capacity WeightSSZ-140 1,40 m 800 l 495 kgSSZ-160 1,60 m 1000 l 570 kgSSZ-180 1,80 m 1150 l 675 kgOpening width Weight1,10 m 245 kg1,30 m 253 kgWidth Weight1,40 m 240 kgTELESCOPIC HOOkLength 1,50 mExtendable up to 2,00 mWeight500 kg800 kg Weight1000 kg1200 kg1400 kgWidthOperating width Weight1,40 m 1,20 m 280 kg1,60 m 1,42 m 300 kg1,80 m 1,53 m 325 kg2,00 m 1,72 m 345 kg2,30 m 2,00 m 385 kg2,50 m 2,18 m 410 kg2,70 m 2,35 m 440 kg2,90 m 2,48 m 470 kg3,10 m 2,68 m 495 kgOn demand:qUICk-CHANGE PLATE - Hauer- Mailleux- TrimaTECHNICS FOR PROFESSIONALS46 years of experience in research and development, design and construction, permanent innovation and the use of state of the art EDP and CAD/CAM technology are ensuring the leading position. A quality control system following to ISO 9001 provides best quality and production efficiency. Today HYDRAC is known as a high-tech production facility for agricultural- and municipal equipment with around 120 employees. More than 6500 machines are annually produced. HYDRAC is very keen on the permanent education and a high sense of responsibility of its emplo-yees, who are the base for the permanent progress.The HYDRAC production facilities in Upper Austria - the heart of Austria’s main industrial region - have been expanded several times within the last years. Latest CNC machines and robots ensure an economic production. Product range: Snow ploughs, winter service and municipal equipment, front-end loader, front linkage and front power take off.Perfect service: Extensive consultation and quick customer service is at the top of HYDRAC’s prioritiesAn additional plus: Special wishes can be fulfilled on short noticeAT-4523 Sierning | Primitstraße 4Tel +43-7259-6000-0Fax +43-7259-6000-40www.hydrac.com | office@hydrac.comDealer:Errors and modifications reserved. Information subject to change without prior notice. | 40.800.833 – 10/12 | © HYDRAC 2012PRODUCT RANGE FRONTSYSTEMS• Front linkage• Front PTO• Hydraulic release MUNICIPAL EqUIPMENT• Snow blades• Snow ploughs• Sand/Salt spreaders• Snow blowers• Hedge cutters• ExcavatorsHYDRAC Pühringer GmbH&CoKGkommunal- und Landtechnik
