S800x - Zero Turn Mower Full Specification Brochure

1740_SPR_FLY_0913ENGINE • 31 gross hp* Vanguard™ or 30 gross hp^ Yanmar™ diesel engine options• Two-stage industrial air cleaner extends engine service life• Easy access oil drainDRIVE SYSTEM• Dual pumps and wheel motors• 7” cooling fans mounted on top of dual hydros• Hydro fluid reservoir and hydro filter• 5/8" hoses supply a constant flow of fluid cooling the hydro system• Ground speed up to 10 mphMOWER DECK• 72" or 61" cutting widths• iCD™ Cutting System with striping kit• Cast-iron greaseable spindles for longer usable life, 1" shaft with top access grease fitting, 6-bolt 8" flange design adds strength and greater dispersal of energy to deck assembly• Electric deck-lift makes for easy cut-height adjustment; cutting height ranges from 1.5" - 5" in 0.25" incrementsCHASSIS• Heavy-duty C-channel, 7-gauge frame rails • Premium adjustable seat with arm rests• Flip-up seatFUEL SYSTEM• Twin 6-gallon rugged, impact resistant fuel tanks with extra large filler necks• Switch for fuel source (gasoline only)• Top-mounted fuel pick-up with Viton® sealsOPERATOR CONVENIENCE• Ergonomic control panels with cup-holder and storage compartment• Adjustable solid steel padded control armsACCESSORIES• Collection System (61"), Mulch Kit, Suspension Seat, Suspension Seat Insert, Flat-Free Caster Tires, Snowblower, Cab200PROFESSIONALPROFESSIONAL800PROFESSIONAL175PROFESSIONAL150PROFESSIONAL50PROFESSIONAL125PROFESSIONAL200PROFESSIONAL75PROFESSIONAL30PROFESSIONAL5PROFESSIONAL20MODEL ENGINE DECKS800XY30D w/S800X/61 30 gross hp^ Yanmar™ Diesel 61"S800XBV31 w/S800X/61 31 gross hp* Vanguard™ 61"S800XY30D w/S800X/72 30 gross hp^ Yanmar™ Diesel 72"S800XBV31 w/S800X/72 31 gross hp* Vanguard™ 72"MOWS UP TO6 ACRES/HOURBASED ON 80% EFFICIENCY * All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton ^ Power levels rated by engine manufacturerThe visibility and versatility of the S800x cannot be beat. Its out-front design is perfect for trimming around trees, bushes and landscaped areas with ease. Be even more productive with a selection of accessory and attachment options.ENGINE Make (Gross Horsepower) Vanguard™ (31*), Yanmar™ Diesel (30^) PTO Electric Cylinders 2, 3 (diesel) Starting Electric Fuel Capacity (Total) 12 gallonsMOWER Cutting Width (In.) 72, 61 Cutting Height (In.) 1.5 - 5 Deck Construction iCD™ Cutting System with striping kit Spindles Cast-iron, greaseable Belts Single B-section Kevlar™ corded belts CHA SSIS Frame Rail C-channel, 7-gauge Bearings Greaseable tapered caster spindle and tapered wheel bearings Finish Automotive quality powder coat paint with U.V. protectionDRI VE TRAIN Transmission Dual pumps and wheel motors with 7" mounted cooling fans Drive Axles 1.25" Tapered Drive Tires (in.) 24 x 12-12 Caster Tires (in.) 13 x 6.5 (rear); 11 x 4 (front)GROUND SP EED Speeds-fwd. (mph) 0-10 Speeds-rev. (mph) 0-5DIMENSIONS Overall Length 115.5" Overall Width : deflector down / up 88" / 74" (72"); 73" / 61.5" (61") Dry Weight (lbs.) 1677 (72"); 1514 (61")OP ERAT OR C ONTROL & C OMF OR T S YS TEMS Seat Package Premium adjustable seatCertified ROPS with retractable seatbelt Standard Instrumentation Hour meter Controls/Safety Group Seat actuated engine kill, blade, clutch safety switch, parking brake, safety circuit Parking Brake/Safety Circuit Disk Type Accessories Collection System (61"), Mulch Kit, Trailer Hitch Kit, Suspension Seat, Suspension Seat Insert, Flat-Free Caster Tires, Snowblower, CabWARRANT Y (See Deale r f o r Det a i ls) Engine 2-Year Limited Manufacturer’s Warranty (Yanmar) 3-Year Limited Manufacturer’s Warranty (Vanguard) Balance of Machine 4-Year Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Belts, Tires, Brake Pads, Hoses, Battery, Blades: 90 days‡ * All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton ^ Power levels rated by engine manufacturer ‡ See dealer for warranty details© 2013 Briggs & Stratton Power Products Group LLC. All Rights ReservedAn electric switch lifts the deck to make maintenance a snap.30 gross hp^ Yanmar™ diesel engine option.The pivoting rear axle in conjunction with the floating front frame allows the S800x to follow the contours of the landscape for a precise, manicured finish.www.SnapperPro.com Not all models available in California. Models subject to change without notice. 200PROFESSIONALPROFESSIONAL800PROFESSIONAL175PROFESSIONAL150PROFESSIONAL50PROFESSIONAL125PROFESSIONAL200PROFESSIONAL75PROFESSIONAL30PROFESSIONAL5PROFESSIONAL20Optional 60" 2-stage snowblower and cab available.
