Rijer - 2 Row Mounted Potato planter
From the hopper (1) the potatoes slide onto a wide conveyor belt (2), which carries them between the electronically controlled adjustable apertures (3), the bottom half of which is bent inwards. The potatoes then travel towards the two conical formed discs with a flat outer rim. Alongside the wide conveyor belt (2) there are two narrow conveyor belts(7), which are fed by the supply discs (4) which counter rotate at a speed adjustable to that at which the machine is traveling over the field. The seed supplied by the conveyor belt (2) are spread out by the rotating discs (5) and picked up and carried to the narrow conveyor belts (7).
The discs (5) are closely surrounded by a wall tapered in the centre. The seeds picked up by the discs (5) are discharged by the rubber discs (4) to the conveyor belts (7). The peripheral velocity of the discs (5) is higher than the velocity of the conveyor belts (7), so that the seeds tend to crowd together in the extension of the wall adjustable baffle plates (6) are positioned just above the conveyor belts (7). These plates are caused to vibrate by the tractor pto. This selective vibration helps to form a regular row of seed potatoes on to the belt, which the spiked roller (8) then conveys to the furrow to be planted (9). The potatoes are covered with soil by discs (10). No supervision is required on the machine. An electronic controlled feed unit (3) guarantees a regular flow onto the central belt (2).
Pressure on the rubber flap by the potato flow activates an electronic switch, which then activates the adjustable gate mechanism (3).
Three row bed potato planter
To meet customer requests this unique planter has been developed to plant chitted-, irregular- and large tubers in preformed beds gently and accurately.
- Ridginghood in stead of rowdiscs 275x1500
- Ridginghood in stead of rowdiscs 290x1800
- Adaption from 3 row to 2 row machine
- Hydraulic hill side ram as of 2/3 row machine
- Electric hill side ram 2/3 row machine
- Electric hill side ram 4 row machine
- Hydraulic row marker on 4 row machine
- Gear set 1x right + 1x left
- Powder applicator over conical discs as of 2 rows
- Counting-control unit with sensorsets for 2 rows
- Extra counting sensor per row
- Wheel track cultivator for 4 row machine
- Road lights set incl. safety sign boards
- Controller with hydraulic/electronic control
- Extra at a 2 row machine
- Extra at a 3 row machine
- Extra at a 4 row machine
- Fertilizer equipment 2 row machine 75 cm
- Fertilizer equipment 2 row machine 90 cm
- Fertilizer equipment 3 row machine 75 cm
- Fertilizer equipment 4 row machine 75 cm
- Fertilizer equipment 4 row machine 90 cm
- Fertilizer equipment 4 row machine trailed
