Bale & Pallet Trailers


A range of tandem axle flatbed bale & pallet trailers. Available in 10, 12 & 14 tonne models. The Western Bale & Pallet Trailer range has a chassis constructed from 6mm formed steel section, with a 4mm steel plate platform. The standard version is designed to give a minimum of 25% braking at 32kph (20mph) and in many cases the standard models will provide up to 40% braking. Two new variations, the LX and HS models have been introduced for 50 kph tractors and high speed tractors. Strong, robust design Each Bale & Pallet trailer in the range has a strong, robust design, with usability built-in.

  • 4mm Steel floor
  • 2′ Headboard
  • Hydraulic brakes
  • Sprung or rocking beam axles
  • Height adjustable sprung drawbar
  • Strap box
  • LED side marker lights
  • Load sensing valve for hydraulic brakes

  • Grain chute
  • Grain sock
  • Swivel drawbar eye
  • Anti jack-knife system
  • LED Flashing beacon kit
  • Hydraulic jack
  • Rear drawbar with brakes and electrics
  • Roll over sheet Inside steps
  • Air and hydraulic brakes
  • ABS braking
  • Reversing/working light kit
