Cord King
Cord King - Model M24-30 - Bar Saw Firewood Processors
FromCord King
60 HP Turbo Diesel Engine of your choice. Hydraulic-driven 404 harvester bar and chain with pressure relief system. Gravity feed bar oiler system with large 1 ½ gallon capacity. 34 ton splitter force. 6- or 8-way fixed splitting wedge. Adjustable log length gauge. 16` long infeed Conveyor with continuous chain drive feeding. 3-leg manual folding live deck. Operator platform with deluxe seat. Lexan safety screen for excellent visibility. Firewood Cleanout Grate. Fuel Capacity: 20-gallon fuel tank. Hydraulic Reservoir Capacity: 65 gallons. Hydraulic Oil Cooler Standard: 35,000 BTU/hr. 10k lbs tandem axles with electric brakes and running lights. 2 5/16″ Ball Hitch.
Most popular related searches
firewood processor
hydraulic logging
firewood
log deck
harvester bar
log grapple
firewood saw
logging system
chain feeding
log splitting
- Hydraulic Folding Log Deck
- Extended live deck (8`) with bearing upgrade
- 6- or 8-way hydraulically adjustable wedge
- Hydraulic log stop adjustable 12-24" length
- Automatic clamping
- Extended infeed conveyor to 20′
- Extra live deck legs, dual drive available
- Operator safety cage or operator canopy (roof)
- Heated operators cab
- Air conditioning hydraulically driven or 120V plug in
- 24` to 40` stand alone offloading conveyor (radial stacking)
- 12` or 16` integrated offloading conveyor
- Overhead log grapple assist (crooked wood)
- Available Log lifting system with double 2” Hydraulic Cylinders available
- Production Rate: up to 4 full cords/hr
- Cycle Time (cut and split): every 4 seconds
- Maximum Log Diameter: 24”
- Maximum Log Length: 30’ (butt on the deck)
- Estimated Fuel Consumption: 1.5 - 2 GPH
- Weight: 7,280 lbs
- Transport Dimensions: 8’-0” wide, 23`-0" long, 12`-0" high
