HORSCH Joker - Model RX -Compact High Speed Disc Harrow
The HORSCH Joker RX is a compact high speed disc that is ideal for precise and fast shallow tillage. Built on the robust foundation of the European Joker RT, the Joker RX has been meticulously adapted for the American market, inheriting all the esteemed qualities and capabilities of its predecessor. This includes its proficiency in shallow stubble cultivation, seedbed preparation, residue mixing, and mechanical weeding. After undergoing specific design modifications in the U.S., the Joker RX emerges as even more suited to American farming needs. With a higher underframe clearance and more space between the two rows of discs, the Joker RX is capable to effectively handle large corn residues, making it an indispensable tool for the diverse and demanding agricultural practices found across the United States.
Compact disc harrow with high clearance as one discs is fitted on one arm with rubber torsion suspension
- Produces a high amount of fine soil in the germination horizon
- Efficient consolidation in the germination horizon
- Resistant to long harvest residues and shallow cultivation
- High clearance with one disc per arm
- Optimum penetration characteristics due to aggressively serrated hollow discs and high machine weight
- Working speed up to + 10 mph
As a trailed version, the high speed disc is available in the following working widths: 20, 25, 30, 35, 40 ft. The operational speed of up to 12 mph allows for high work rates. To precisely control the discs in the soil, the Joker RX is equipped with a wide rubber torsion suspension. This allows for a high clearance for organic material and reduces the chance of plugging. In addition to that the 17° and 17° degree angle helps to evenly work the ground and achive a superior reults. The serrated annular discs as well as the weight of the machine guarantees penetration of the machine even in dry conditions.
Depending on the equipment of tractor, the farmer can choose between an articulating hitch with cat. III or VI or an hitch kit with at. IV. Due to these and other options the Joker RX can be optimized to the farmers requirements. To prevent the machine from bouncing while working in the field, the transport wheels are equipped with an intelligent suspension system called SoftRide.
Personal contact
Simply use our contact form to tell us what you are interested in and how we can best contact you. We will get back to you immediately and advise you personally, without obligation and free of charge.
Disc serrated Ø 20"
- Disc serrated Ø 20"
- Excellent penetration of the soil
- Intensive mixing
- Different hardness grades in one disc
The serrated disc with a diameter of 20`` can be used in different situations. For working depths up to 6``, it reliably penetrates the soil. The serrated cutaways allow for an excellent incorporation of high amounts of straw. The serrated profile almost completely prevents the discs from stopping even in very light soils. Small disc diameter for high rotational speeds and a high production of fine soil.
- Shallow primary tillage
- Efficient seedbed preparation
- Mechanical weeding
- Incorporation of fertilizer /manure
- The packer is connected to the chassis for a comfortable road transport
- Working depths up to 2``
- Good production of fine soil
- Crushing of cover or catch crops
The Vortex disc is ideal for a shallow use up to 3 inch. Due to the large contact area, a lot of material is crushed but is only mixed in to a limited extent.
- Shallow primary tillage
- Efficient seedbed preparation
- Mechanical weeding
- Incorporation of fertilizer /manure
- The packer is connected to the chassis for a comfortable road transport
- High contact area due to 2.7`` wide ring elements
- Additionally mixes in organic material
- Can be converted to a winter packer
- Weight per m working width: 265 lbs
The RingFlex packer impresses due to its excellent load-carrying capacity on light and medium soils. Moreover, it guarantees a good consolidation. Depending on the conditions, it can also be used as a winter packer by removing individual rings.
- Deep consolidation with loose soil surface
- High levelling capacity due to intermediate levelling tine
- Self-cleaning, without scrapers
- High operational reliability
The RollFlex packer ensures a high reliability on changing soils even in wet conditions. Due to the deep consolidation, loose soil is compacted, clods are crushed and an optimum environment with an optimum ratio of water-bearing and air-ducting pores are created.
- Excellent rolling characteristics
- OptiRoll packer Ø 29"
- Weight per ft working width: 253 lbs
Due to its excellent rolling characteristics and its closed design, the OptiRoll packer is ideal for light soils with little structure. Due to the low horsepower requirement, it is also perfect for changing soils. Partial consolidation in the area of the rings.
- Shallow primary tillage
- Efficient seedbed preparation
- Mechanical weeding
- Incorporation of fertilizer /manure
- The packer is connected to the chassis for a comfortable road transport
- With single or double support wheels
- Can be adjusted to ensure ideal working conditions
- Tyre size: 340/65R15
Depending on the application and the conditions, the Joker RX can be equipped with front support wheels. They guarantee a precise depth control and prevent the machine from sinking in soft conditions.
- Shallow primary tillage
- Efficient seedbed preparation
- Mechanical weeding
- Incorporation of fertilizer /manure
- The packer is connected to the chassis for a comfortable road transport
