Vermeer - Model CT616 - Compost Turner

• Stay in control using the cabled remote controller that will reach all the way to your tow vehicle.
• Adapt to site conditions with the vertical height adjuster. Height setting indicators help operator monitors height.
• Process material more efficiently with the large drum size.
• Transport the CT616 easily using the hydraulic hitch fold.
• Enhance operator safety with automatic drum shutdown.
• See your Vermeer dealer for comprehensive service and genuine Vermeer replacement parts.

The CT616 by Wildcat is a towable, self-powered unit that is able to turn a windrow 6` (1.8 m) high by 16` (4.9 m) wide. It features a 40" (101.6 cm) tip-to-tip drum diameter, and its 275-hp (205.1 kW) engine offers a maximum turning capacity of 3000 tons (2721.6 tonnes) per hour.

Drum engagement is easy with the electronically controlled, hydraulically engaged clutch drive system with dual reduction. The first reduction includes a high-efficiency synchronous belt drive system for low maintenance and long service life; the second reduction includes an enclosed oil bath 80-4 roller chain drive.

The CT616 also features an enclosed engine compartment that helps keep the radiator clear, minimizes UV exposure damage to hoses and wiring and features convenient service access to both sides of the engine.

General Dimensions

Max width (operational): 25.5` (7.8 m)
Max width (transport): 8.3` (2.5 m)
Max height (operational): 14.7` (4.5 m)
Max height (transport): 11.5` (3.5 m)
Max length (operational): 21.3` (6.5 m)
Max ground clearance: 22.5" (57.2 cm)
Weight: 17,800 lb (8073.9 kg)
Tongue weight: 1800 lb (816.5 kg)

Engine

Make and model: John Deere PowerTech RG6090HF Tier 3
Number of cylinders: 6
Horsepower: 275 hp (205.1 kW)
Battery: 12V 660 CCA

Processing Size

Windrow width: 16` (4.9 m)
Windrow height: 6` (1.8 m)

Turning Style – Drum

Drum diameter (including flails): 40" (101.6 cm)
Length of drum: 15.8` (4.8 m)
Number of flails: 92
Flail dimensions: .5" x 4" x 12" (1.3 cm x 10.2 cm x 30.5 cm)
Drum wall thickness: .6" (1.5 cm)
Drum clutch: Electronically controlled hydraulically engaged clutch with accumulator

Frame

Mainframe: Constructed of 4" x 4" x .25" (10.2 cm x 10.2 cm x .6 cm) structural steel tubing with continuous welding
Tires: 48" x 31" (121.9 cm x 78.7 cm) 10-ply [main frame (2)], 425/65 R22.5 20-ply [low-speed transport option (2)]

Controls

Display type: LCD readout and LED warning lights
Gauges: Murphy Powerview with monitors — engine rpm, coolant temperature, oil pressure, volts, engine hours, fuel level, engine load and engine fault codes
Controls: Engine ignition, throttle, clutch engage/ disengage, raise and lowering of machine, tongue extend and retract, thrown object deflector raise and lower, tethered remote control box located in tow vehicle

Tow Vehicle Requirement

Min tow vehicle weight: 11,900 lb (5397.7 kg)
Min ground speed: 44 fpm (13.4 m/min)
Max towing speed: 20 mph (32.2 km/h)
Min horsepower: 60 hp (44.7 kW) with optional low-speed creep gear
Hitch type: Clevis style

Options

Low-speed transport package
Stainless steel processing tunnel
Spray bar attachment
Work lights
Loader hitch
