Alphafluid Hydrauliksysteme Müller GmbH

Directional Valves


Distributing valves are used in an open circulation. They provide various consumer loads with the delivery flow of the pump. The distributing valves of ALPHAFLUID are available in mono design or modular circuit board. The valves with electrical resp. electronically proportional control don’t need any additional control pressure supply. The hydraulic auxiliary energy for the build on input unit is taken from the main oil circulation and will be lead towards the triggered consumer load via the moved distributor valve.

  • Solid construction
  • Low weight
  • No additional control pressure supply
  • Parallel operation possible
  • Shock absorbing action of the distributor valve that is smooth switching on-   and switching off of the consumer loads
  • Flexible modular design (modular circuit board)
  • Excellent sensitivity due to electronic proportional operation
  • Add-on kit for directional valves

  • Manually operated
  • Electrical (S/W)
  • Electronically proportional
  • Manually/electrical combined
  • Manually/electronically proportional

  • Construction equipment
  • Agricultural machinery
  • Forest machinery
  • Fork lift-truck
