Disc Mowers

From

0

DEUTZ-FAHR mowers are now sturdier than ever. With a choice of three-point or central frames, a reinforced cutter bar and a V-belt transmission system, these mowers are designed and built for extensive, heavy-duty use.

Cutterbar with Triangular Discs
The DEUTZ-FAHR cutterbar is designed for low maintenance and offers a very quiet operation. Operators will immediately love the virtually quiet operation of the cutterbar – convenient during a long and busy working day. The long curved gear wheels run smoothly in oil and provide lots of power transmission with little slack. The fully welded cutterbar with overlapping C-profiles makes for a very stiff and strong design, ensuring very high level of durability.

Counter-Rotating Three Bladed Discs
With three blades per disc DEUTZ-FAHR mowers are constantly cutting. This means a third less load per blade and an even load on the drive and smoother power usage in addition to producing a neat, cleanly cut stubble. Each steel blade is precisely angled to immediately convey the cut crop upwards with a combination of mechanical action and air flow.

DiscMaster 100
DiscMaster 117 – 122 – 124
Light-Weight Disc Mowers
DiscMaster 100 series is based upon the fully welded DiscMaster cutterbar, which is designed for low maintenance and quiet operation. The cutterbar has a high oil capacity, ensuring a very low working temperature and the long curved gear wheels run smoothly in oil and provide lots of power transmission with little slack.
Spring Loaded BreakBack
If encountering an obstacle, the mower will swing backwards, to protect the cutterbar. By reversing, the mower is reset into working position.
Fast Lifting On Headland
The mower is easily lifted via a hydraulic cylinder without activating the tractors 3pt linkage. The advantage is less wear on tractor and machine, as the PTO stays in the same position, minimizing vibrations in the transmission.
Transport Solution
When in transport, the mowers are folded to a vertical position well behind the tractor. The center of gravity is close to the tractor, which ensures excellent weight distribution and transport stability.

DiscMaster 200
DiscMaster 228 – 232
Side Mounted Disc Mowers
The DiscMaster 200 models are lightweight, simple mowers with a compact but durable design, for maximum output at a competitive price. They are offered in working widths of 2.8 and 3.2 m.
Protection of Cutterbar
An integrated BreakBack system will protect the cutterbar from foreign obstacles. If hitting an obstacle, the BreakBack system will swing the machine backwards and over the obstacle and then return it to the original working position.
Flexible Suspension
DiscMaster 200 models offer a very flexible suspension, providing perfect ground contour following. Due to the very flexible suspension, the mowers are exceptionally well qualified for work on slopes and in hilly conditions, with an operating angle of 35° up and down.

DiscMaster 300
DiscMaster 328 – 332 – 336 – 340
Extensive Working Width – Low Weight
DiscMaster 300 rear mounted range boasts an extensive working range of 2.8-4.0m, with corresponding weights ranging from 810-940kg, which means the machines can be operated with tractors starting from only 50 hp,
Centre Pivot Suspension
The DiscMaster 300 series is centre suspended to give an even weight distribution across the complete mower width. Faster and more precise adaptation to ground contours is also achieved
because of the centre suspended design. The benefit is less skid wear and optimum protection of the stubble.
Vertical Transport Position
DiscMaster 300 series is folded hydraulically into a vertical transport position up to 125° depending on model. The low gravity point ensures excellent weight distribution, with the weight of the mower close to the tractor.
Cutterbar Protection
To offer maximum protection of the cutterbar, DiscMaster 328-332-336-340 are fitted with a BreakBack solution. When encountering an obstacle the BreakBack will swing the machine
backwards and over the obstacle, returning to its original working position, once the obstacle has been passed.
Adjustable PTO Speed
DiscMaster 300 series comes factory fitted with the option of being operated with either 540 or 1000 rpm. It requires no additional accessory. All that is needed is simply to turn the main gearbox on the suspension 180°.

DiscMaster 400
DiscMaster 428H – 432H – 440H
Centre Suspended Mowers
DEUTZ-FAHR offers a centre mounted plain disc mower with a hydraulically suspended design in working widths of 2.8, 3.2 and 4.0m.
Hydraulic Suspension
The DiscMaster 400H range is designed with a hydraulic suspension that offers improved ground adaptation. The ground pressure of the mowing unit is easily adjusted, to allow adaptation to varying field conditions, ensuring an even cutting height. The ground pressure is continuously and
quickly adaptable, by using the lever on the suspension.
Protection of Cutterbar
The DiscMaster 400H series is fitted with an automatic BreakBack system to protect the cutterbar. If an obstruction is hit in the field, the mowing section will swing backwards and up. This gives maximum protection of the cutterbar. No need to stop – no time lost.
Safe and Easy Transport
For transport the mower is swung hydraulically into horizontal position behind the tractor. Fast and easy conversion, with no need to leave the tractor.
Excellent Power Transmission
DiscMaster 400H is equipped with a direct drive system from the gearbox to the first disc. This ensures an efficient power transmission and allows you to take full advantage of the whole width of the cutterbar.

DiscMaster 328F - 332F – 332XF
Less Weight, More Go
With a working width of 3.2m and an operating weight of only 690 kgs, the DiscMaster 332F requires as little as 55hp to operate. Run in a combination with a 4.0m on the rear, would give you a mowing combination capable of effortlessly handling up to 6.8m crop.

Responsive Mowing
To offer maximum protection and lessen the shock loads on the complete machine, the cutterbar will move backwards and up, letting any obstacle pass without risk of damage.
Remarkable Adaptation Range
The DiscMaster 332F is exceptionally well adapted to varying field conditions and contours. At standards settings the cutterbar has a remarkable 430mm upwards and 210mm downwards
adaptation range, in combination with transverse pivoting range of 17°. This wide spectrum allows the machine to follow the ground in all conditions without overloading the cutterbar.
Two-Speed Driveline
Standard PTO speed is 1000 rpm. However by simply switching driveline pulleys, 750 rpm for reduced fuel consumption can be achieved. This makes it possible to maintain the correct
PTO speed, but using reduced engine revs, creating an opportunity for lower fuel consumption. An innovative solution solving the problem of front PTO systems not offering an economy speed.
332XF with Actively Driven Swath Former
DiscMaster 332XF is a front mower with an actively driven swath former, designed for both narrow swathing and wide spreading. With the option of 3 different swath widths (1.00, 1.15 and 1.30m) and wide spreading up to 2.20m, this machine offers exactly the flexibility that most farmers are looking for. Narrow swaths that will go well in-between the tractor wheels, or wide spreading for fast wilting of crop changing between different swath widths is intuitively done in very little time– no tools required.

DiscMaster 390 – 395
Output and Energy Consumption in Perfect Combination
DiscMaster 390-395 provides efficient performance with its 8.70 and 9.50m working width paired with a low weight design. They are an eco-friendly, energy saving solution purposely build for low operating costs in terms of power and fuel consumption, with power requirements starting at only 120hp. The low weight of only 1360 and 1500 kgs respectively, together with the ideal weight distribution that butterfly combinations offer, gives the optimum combination of low power requirements, low weight and high efficiency.
Two Mounting Options
To ensure optimal overlap between front and rear units, the mowing units can be mounted in two positions on the suspension arm.
Centre Suspended Mowing units
The mowing units are centre suspended offering an even weight distribution across the complete mower width. Faster and more precise adaptation to ground contours is also achieved due to the centre suspended design.
NonStop BreakBack System
The DEUTZ-FAHR BreakBack system protects the cutterbar from foreign obstacles. If hitting an obstacle, the BreakBack system will swing the machine backwards and over the obstacle, automatically returning the mower to working position, once the obstacle has been passed.

DiscMaster 624T – 628T – 632T Farmer
Compact In Size - Massive In Features
DiscMaster 600T series is available in working widths of 2.4, 2.8 and 3.2m. The mowing units are suspended in the centre of gravity via a large suspension spring. This design provides an even weight distribution across the entire mowing width, as well as a constant, faster and more precise adaptation to ground contours.

Clever Transport Solution
DiscMaster 600T is folded into a 125° vertical transport position using a hydraulic cylinder. The low gravity point during transport, with the weight of the mower close to the tractor, provides an excellent weight distribution, even during high speed road transport.
Protection of the Cutterbar
To offer maximum protection of the cutterbar, these machines are fitted with the Non-Stop
BreakBack system. When encountering an obstacle, the BreakBack system will swing the machine backwards and over the obstacle and then return it to the original working position.
Easy Adaptation to Varying Crop Conditions
DiscMaster 600T offers two conditioner rotor speeds, 600 and 900 rpm, which can
be easily changed by simply switching pulleys, to adapt to different conditioning requirements. At low conditioner speed, fuel consumption is minimized.
Aggressive Conditioning
Due to the nylon tines fitted to the conditioner, the total weight of the machines is kept to a minimum, while keeping an aggressive conditioning. The fixed conditioning fingers are made from high quality nylon, to make them very rigid.
Adjustable Gearbox Speed
The machines also offer a large degree of operating adaptability, as they are factory fitted with the option of being operated with either 540 or 1000 rpm. It requires no additional accessory. All that is needed is to turn the main gearbox on the suspension 180°. Wide spreading equipment is also
fitted as standard on the machines.

DiscMaster 632T Pro
High Spec Mower
The DiscMaster 632T Pro has been designed for professional use during a busy and
demanding harvesting season. Features include a two speed gearbox, easy access to both cutterbar and conditioner rotor, low maintenance SemiSwing steel tines and hydraulic, pulled suspension.
Pulled Suspension
The Free Float Suspension concept is the optimum solution to precise and trouble-free mowing. The mowing unit is centrally suspended to give more precise ground contour following. The mowing unit features a pulled suspension system to allow the cutting unit to independently float over ridges and contours. This ensures accurate, close cutting performance in all conditions.
Two-Speed Gearbox
The DiscMaster 632T Pro is fitted with a 2-speed gearbox for conditioner speeds of 900 or 600 rpm. This allows you to choose between intensive conditioning or low fuel consumption when the crop only requires limited conditioning effect
Transport
The DiscMaster 632T Pro is folded hydraulically into a vertical transport position. The low gravity point during transport provides an excellent weight distribution, which protects the headstock and tractor from excessive forces resulting from humps and bumps.
SemiSwing Steel Tine Conditioner
The SemiSwing conditioner system combines the aggressive conditioning seen from fixed fingers with the excellent tine protection typically associated with free swinging tines. The benefits from the SemiSwing system are very aggressive conditioning and drastically diminished maintenance costs.

DiscMaster 600F
DiscMaster 628FT – 632FT/FR – 635FT
The DiscMaster 628FT-632FT/FR and 635FT feature an improved design of the pulled floating suspension and more accurate ground following. The gravity point is close to the tractor and with the very compact design, excellent view of the entire mowing area is guaranteed.
Non-Stop BreakBack
To ensure maximum protection of the cutterbar, the Non-Stop BreakBack solution is implemented. During normal operation, the cutterbar is angled downwards, but if the BreakBack is activated, the cutterbar angle changes to a horizontal position, due to the geometry of the machine. This prevents the machine from damaging the ground surface.
Superior Suspension Protecting Ground and Machine
Due to the redesigned suspension of the DiscMaster front mounted models, an even better flotation and more even ground pressure is possible. The two large suspension springs have been moved further outwards to provide better side stability, which is reflected in optimum protection of
the stubble and far less skid wear. In addition the innovative suspension design
allows a transverse adaption of 24⁰
SemiSwing Steel Tine Conditioner
The SemiSwing conditioner system combines the aggressive conditioning seen from fixed fingers with the excellent tine protection typically associated with free swinging tines. The benefits from the SemiSwing system are very aggressive conditioning and drastically diminished maintenance costs.

DiscMaster 800
DiscMaster 832T Pro – 832R Pro
Pull-Type Mower Conditioners
Including features such as SemiSwing conditioner, low maintenance cutterbar, FreeFloat suspension, BX swath belt and easy-to-use wide spreading, the DiscMaster 800 series is ready to meet every request with exceptional performance

Pulled Suspension
The Free Float Suspension concept is the DEUTZ-FAHR solution to precise and trouble free mowing. The mowing unit is centrally suspended to give more precise ground contour following. The mowing units feature a pulled suspension system to allow the cutting unit to independently float over ridges and contours. This ensures accurate, close cutting performance in all conditions.

Excellent Protection Against Foreign Obstacles
If an obstacle is hit in the field the pulled suspension allows the mowing unit to swing backwards and up. When the obstacle is passed the mowing unit automatically returns to the working position.
Swathing, Wide Spreading or Double Swath?
DiscMaster 832T is the ultimate solution when it comes to flexibility. The mower can be fitted with wide spreading equipment and a swath belt to give as much flexibility as possible and help you cope with the ever changing conditions. The changeover from single swathing to swath belt or
wide spreading is very quick and done in short time.

SemiSwing Steel Tine Conditioner
The SemiSwing conditioner system combines the aggressive conditioning seen from fixed fingers with the excellent tine protection typically associated with free swinging tines. The benefits from the SemiSwing system are very aggressive conditioning and drastically diminished maintenance costs.

DiscMaster 690T ISOBUS
DEUTZ-FAHR’s top-of-the-line mower conditioner combination offers 9m working width. It consists of an front mounted mower conditioner with 3.2m working width and two rear-mounted 3.2m mower conditioner units. Th DiscMaster 690T is fitted with ISOBUS control, where control and operation is designed around the tractor driver, adding maximum support and convenience during the intensive grass season. New intuitive joystick control ensures excellent control and comfort.
The DiscMaster 690T BX can be set for 3 single swaths, wide spreading or three swaths into one with the swath belt. An extra feature is the fact that the right belt can run in two directions, meaning that it will place grass from 6 m into one swath.
