Pronar - Model PT606 -Double Axle Trailer
PRONAR PT606 Trailer was constructed to meet the customer’s high demands. It is multipurpose and durable. Perfect for both agriculture and municipal use. The universality of the PRONAR PT606 trailer is due to inner width of the loading case (2.42 m), which allows transporting of bulk materials and typical loading euro pallets . The design of the chassis of the trailer PRONAR PT606 is based on close sections profiles, which, unlike open profiles are much more durable.
Most popular related searches
- Permissible total weight: 8900 [kg]
- Load capacity: 6000 [kg]
- Empty weight: 2900 [kg]
- Load volume: 10.1 [m 3]
- Loading space: 10.1 [m 2]
- Loading case inside lenght: 4190 [mm]
- Loading case inside width 2420** [mm]
- Dimensions: length/width/height: 6390/2550/2200 [mm]
- Sidewall height: 500+500 (option) [mm]
- Floor/wall thickness: 4/2 [mm]
- Platform height, measured from the ground: 1160 [mm]
- Wheel track: 1900 [mm]
- Suspension: parabolic springs
- Tyres: 14.0/65-16
- Maximum speed: 40 [km/h]
- Tipping system : 3-side
- Cargo grips ( on the floor): 8 [pcs]
- Tipping cylinder (piston stroke/oil requirement/working pressure) 1540mm/8L/200bar
- Tractor power requirement: 46.8/34.4 [hp/kW]
- Tipping angle (backwards/sides): 50/46 [°]
* technical data for side walls and extensions 500+500mm
** width of the loading case suitable for EUROPALET transport
- Loading case with universal system of sidewalls opening
- Reinforced floor pan with walls central locking system
- Drawbar V type: rigid with Ø40 towing eye
- Rotating turnable
- Braking system: single line air or double line air or hydraulic
- Parking brake with crank
- 12 V lighting system with rear electric socket
- Rear lamps with protective grating
- Coiled connecting cable for the lighting installation
- Rear manual hitch
- Rear conections to second trailer
- Tipping system with cut-off valve
- Three side tipping cylinder
- Side walls made of PRONAR profiles 500mm with rim 60mm with forged hinges and locks
- Rear mudguards
- Wheel chocks + racks (2 pcs)
- Ladder and steps facilitating the access to the Loading case
- Tension slat of the sidewalls
- Chassis color red RAL3000 PRONAR
- Double-component chemically hardened painting materials, UV-resistant
- Sidewalls color orange RAL 2008 PRONAR
- Loading case adapted to transport europallets
- Mechanical support of the loading case
- Rear grain hatch with a lever in a rear wall
- Drawbar V type: fixed with Ø50 towing eye
- Drawbar Y type: fixed with Ø40 towing eye
- Braking system: double line air with ALB (automatic braking force control)
- Overrun braking system
- Tension bars along the sidewalls extensions (2pcs.)
- Laced canvas cover with frame
- Rolled canvas cover with frame with demountable central pipe and lateral supporting pipes
- Sidewalls extensions made of PRONAR profiles 500mm with rim 60mm
- Rear grain chute
- Operator’s platform
- Rear manual, hitch witch shock absorption
- Rear manual hitch MH31-3 V. Orlandi
- Rear automatic hitch IH31-3 V. Orlandi
- Tyres 400/60-15,5
- Water tank (30L) with soap dispenser
- Toolbox (~50L)
- Front mudguards
- Spare wheel hanger on the sidewall ***
- Spare wheel hanger winch
- Spare wheel (separately) 14.0/65-16
- Spare wheel (separately) 400/60 – 15.5
- Warning triangle
- Auger for unloading grain with efficiency 30 t/h ****
- The chute along the entire width of the trailer
- Set of wall supports to maintain the walls in a partially open position for bale transportation*****
- Shock absorber for falling potatoes – two sets of rubber belts, 1,8m of length each, mounted on the sidewall extensions (side extensions necessaary)
- Non standard colours according to RAL CALSSIC codes
