Pronovost - Model P-503 -Dump Body for Snow Removal & Public Works
The P-503 dump body, developed by Pronovost, is engineered specifically for effective snow removal and public works tasks. With a robust capacity of 1.5 tons, it is built to handle significant loads with ease. The interior dimensions of 50 ½ inches by 69 ½ inches ensure ample space for various materials, making it a versatile choice for various heavy-duty applications. This model is equipped with options like the hydraulic pump PHM-3003 and a battery holder, tailored for enhanced functionality in demanding environments. While its design focuses on durability and efficiency, specifications may be subject to alterations as technological innovations advance. Designed without video support, the P-503 dump body exemplifies a practical solution for high-impact industrial needs, reflecting Pronovost`s commitment to quality in farm equipment and public work services.
- Robust chassis and reinforced deck (box rails under the deck).
- Strong, removable profiled panels.
- Hinged side panels (certain models).
- Automatic rear panel opening mechanism (except on P-503).
- Optional grain chute on rear panel.
- Optional maximum tilt angle auto stop on certain models.
- Optional board pockets on certain models.
- Swivel hitch or ball receiver.
- Cylinders and hydraulic hoses with quick disconnects.
- Electric hydraulic pump optional.
- Capacity: 1.5 tons
- Interior dimensions: 50 ½" x 69 ½"
- Dump: Rear
- Axle: Tandem
- Gross vehicle weight rating: 1.5 tons
- Interior box dimensions: 50 1/2" x 69 1/2"
- Bed thickness: 12G
- Side panels: 12" x 12G
- Front / back panel: 12 1/4" x 12G
- Removable panels: 4
- Rear panel opening: From top or bottom
- Platform height: 22"
- Overall length: 106"
- Overall width: 54"
- Overall height: 36"
- Free height at maximum tilt: 10"
- Total height at maximum tilt: 72"
- Tread width c/c: 36 1/4"
- Dumping angle (back): 47°
- Axles: Tandem
- Hubs: 4 bolts
- Hub capacity: 1000 lbs
- Spindles: 1 1/4"
- Wheels: 4
- Wheels dimensions: 8.5" x 8"
- Included tires: 12 x 14 x 8"
- Hitch : clevis/swivel: Included
- Jack: Included
- Cylinder(s): 1 double acting
- Total weight (approx.): 640 lbs / 290 kg
- Design and specifications subject to change without notice.
