Feed Bunks
Al’s Concrete Feed Bunks offer a strong, long-lasting solution for feeding your livestock. Our feed bunks are reinforced using a combination of heavy gauge wire mesh and rebar and manufactured with minimum 7000 psi concrete and water-cement ratio of 0.40 or less. Our precast feed bunks are available in H- and J-styles, and are made with holes and/or inserts within the bunks for easy mounting of accessories, such as posts. We also have feed bunks available for sheep or small calves available, as well as molded or bolt-on end caps for all styles. To prepare your site for a new feed bunk, we recommend they be placed on a 6” thick slab wide enough to allow a minimum 12” wide step on the cattle side.
STANDARD FENCE-LINE BUNK
- 36” Wide and 10’ long
- 24” Cattle Side Height
- 15″ Deep Feed Trough
- 2700 lbs. per section
*End caps molded onto the end of bunks available
SUPER HIGH CAPACITY FENCE-LINE BUNK
- 38” Wide and 10’ Long
- 24 1/2” Cattle Side Height
- 34″ Backside
- 20″ Deep Feed Trough
- 6″ Feed Saver Lip
- 3200 lbs. per section
*End caps molded onto the end of bunks available
STANDARD FENCE-LINE BUNK WITH CUT-OFF LEGS
- 36” Wide and 10’ Long
- 18 ½” Cattle Side Height
- 15″ Deep Feed Trough
- 2500 lbs. per section
*End caps molded onto the end of bunks available
H-BUNK
- 5ft wide and 8ft long
- 3 sizes available, End Caps available
- 26″ height 16″ Deep Feed Trough (Pictured below)
- 28″ Height-14″ Deep Feed Trough
- 30″ Height-12″ Deep Feed Trough
