Fella Ramos - Model 210 FK-S - 260 FK -Front-Mounted Compact Linkage for Disc Mowers

Working width approx.: 2.05 m - 2.50 m

1. Rigid headstock with short, compact attachment and a centre of gravity near to the tractor for optimum efficiency on slopes.
2. The alpine front-mounted mowers can be combined with many tractors thanks to the standard 540 and 1000 rpm as well as clockwise and anti-clockwise rotation.

Rigid headstock for short, compact tractor attachment

The short, compact attachment ensures that the centre of gravity is close to the tractor and guarantees optimum efficiency on slopes in alpine terrain.

Symmetrical, central running thanks to four mower discs

The four mower discs on these types of mower ensure symmetrical, central running, which allows excellent and uniform swath positioning. This has an excellent impact on the conveying effect in downhill operation.

Spring-loaded impact guard system

The spring-loaded impact guard system ensures optimum protection of the mower if an obstruction is encountered when driving.

Lateral movement of the FK-S variant

The lateral movement of the FK-S variant (hydraulic optional) makes mowing on slopes and/or with twin tyres possible without problems.

Uneven ground compensation thanks to pivot travel

The pivot travel of +9° compensates for uneven ground on alpine terrain without difficulty.
