Rolmex - Model NSKN - Mulcher

GH120K works with hydraulic transmission. The front hood allows the adjustment of the degree of mulching. With the support stabilization roller it is possible to adapt to the contours of the ground and to adjust the height of cut. Excavator flails are ideal for working from the top of vegetation down to ground level, where contamination or structures have to be avoided and for reaching material where a tracked mulcher or chipper cannot access. They are ideal for heavy thorn, scrub, light trees and hedgerows. They use a steel high-speed rotating drum, with heavy-duty swinging hammers that fold out of the way if contact is made with a solid object.

STANDARD VERSION GH120

Mulches grass & brush up to 5 cm [2”] Ø (10 cm [4”]) with forestry rotor o suitable for excavators from 2 to 10 tons o predisposed for hydraulic transmission with different motor types at choice o pressure:

• 200-450 bar o recommended
• oil flow: 95-120 l/min o manually operated hood o front protection:
• double chains o rear protection: rubber flap o adjustable rear roller to set the height of cut
• Note: Independent hyd. circuit recommended. 3 hyd. lines required: pressure, return and case drain.
• Machine delivered without hoses or interface plate.
• OPTIONS o variable displacement motor with relief valve, different types at choice o rotation inverter valve o interface plate
