Gason - Model 3PL - Proper Topper

8ft Twin Rotor Proper Topper

PT2R2350-3PL (GPN: 226344)

• Width of cut - 2.35m (7`9")
• Deck width - 2.44m (8`)
• Overall Width - 2.56m (8’5”)
• Trucking - 2.7w x 2.0d x 1.2h
• Shipping - 2.7 x 2.0 x 1.2 (6.5 cubic m)
• Weight - 1160kg
• PTO Speed - 540rpm

10ft Twin Rotor Proper Topper

PT2R2920-3PL (GPN: 224770)

• Width of cut - 2.92m (9`7")
• Deck width - 3.03m (9`11")
• Overall Width - 3.15m (9’11”)
• Trucking - 3.2w x 2.0d x 1.2h
• Shipping - 3.2 x 2.0 x 1.2 (6.5 cubic m)
• Weight - 1300kg
• PTO Speed - 540rpm

• Designed for sharp, clean cutting of pasture, with discharged cuttings spread evenly behind without windrowing
• Cutting design eliminates wheel marks in after cow topping operations
• Adjustable rear deflectors for rear discharge and even spread
• Hydraulically adjustable rear guard offers closed and open back for discharge control
• Improve your pasture and increase production with regular topping of paddocks with the Gason Proper Topper

Standard Features

• Deck Material - 6mm - Deck, fully welded top with 8mm side plates
• Deck Profile - Folded easy clean deck design including an open back for more even spread of cutting
• Gearbox - 130HP Bare-Co 3 gearbox driveline incorporating torsion rubber couplings
• PTO Shaft - Bare-Co 8 Series PTO
• Clutch - 4 Plate clutch with over-run
• Finish - 2 Pack painted deck
• Skids - 8mm Height adjustable side with simple "lock and dog" adjustment including 100 x 12mm Hardened steel skids
• Rotor Bar - 100 x 11mm Spring steel rotor bars
• Blades - 100 x 9mm Swing back blades on hardened bushes
• Linkage Mounting - Cat 2 and 3 compatible with high tower 3PL pick up points
• Front & Rear Chains - Galvanized safety chains with rod replacement system
• Rear Safety Guard - Hydraulically operated rear safety guard

• Dual mulching blade kit fir a finer cut and better spread of material
