Model GF-3, GFR-3, GF - Retractable for Sampling Grains, Granulars and Pellets
For sampling grains, granulars and pellets, GF-type samplers offer different mounting options, and are designed simply. They feature a 316 stainless steel tube mounted at a 45-degree angle to the material flow and a slot that faces downstream between sampling periods. When signaled by the control system, the tube rotates 180 degrees so that the slot faces directly into the material flow to capture a cross-sectional sample which flows by gravity into a collection vessel. Models are available in air- or electric-drive systems. The air-operated GF Retractable retracts back into the mounting spool between cycles and is available for vertical or sloping lines.
Designed with precision, built by hand
QM&M delivers precision to manufacturers that receive bulk raw materials, blend raw materials or manufacture by continuous or batch process.
No matter the manufacturing condition – powders, granules, pellets, chips, grains, pharmaceuticals, plastics and food products – QM&M understands the unique sample needs in gravity flow lines, screw conveyors, hoppers, drop-out truck and rail loading chutes, pipelines, silos and tanks. Our experienced sampling specialists provide professional recommendations to help you achieve your particular sampling and monitoring results. We can help you determine the right sampler for the job, based on your unique sample characteristics, including material flow, pressures, space availability and sampling location.
Then we build every dry material sampler by hand to ensure it meets your tough standards for trouble-free performance.
Contact our sampling specialists to customize a durable QM&M sampler for your operation.
